«Nim‐Mh/Ni‐cd»batteryprogram
Thisprogramallowsyoutocharge/dischargeyourNi‐xxbatteries.TheworkprinciplesarethesameforNi‐MhandNi‐Cd,onlythedeltaPeak
valuesaredifferentfollowingtheprogramyouchoose.Pleasemakesuretoattachthematchingbatteries(Ni‐MhorNi‐Cd)whenusingoneor
theotherprogram.


Charge
ThisfunctionallowsyoutochargeyourNi‐xxbattery.Justindicatethemaximumchargecurrent,andlaunchthe
chargeprocess.EndofchargewillbedetecteddependingofthedeltaPeakvaluesenteredinthe“UserSetProgram”
‐>“Ni‐xxsensitivity”.

Cycle
Thisfunctionallowsyoutocycleyourbatteriestobringthembacktotheiroptimalperformances,ortogetridof
the“memoryeffect”ofthebattery.Nickelbatteriesdevelopamemoryeffectwhentheyarenotused/dischargedat
theirmaximumcapacity.Aftersometime,theymemorizethecapacityrequestedduringthelastoperationsandwill
behaveasiftheyhadthatcapacityasamaximum.Cyclingthemfromtimetotimewillallowthemtorecovertheir
fullperformances.Youcanselectthenumberofcycles(fromoneupto5),andyoucancheckthecurrentdrawn
orchargedonthescreenoncetheprocesslaunched.

Discharge
Thisfunctionsallowsyoutodischargeyourbatterywithacurrentbetween0.1Ahand1Ah,andadischarge
voltagelimitbetween0.1and25Volts.Thevoltageyouwillinputmustmatchthevoltageofthebatterypack,not
thevoltageofasinglecell(expectifyouconnectasinglecelltothecharger).


