«PbBattery»progam
ThisprogramallowsyoutochargeordischargeyourLeadAcidbatteries.


Charge
ThisfunctionallowstochargeleadAcidbatteriesfrom2upto20Volts.Pleaseinputthechargecurrentand
nominalvoltageofthebatteryconnected.PleasenotethatLeadAcidbatteriesshouldbechargedslowly,with0.1C
chargecurrent(1/10oftheirtotalcapacity).Itisnecessary,inmosttime,todisablethesafetytimertoavoidpartial
charge.

Discharge
Sameasabovefunction,fordischargingthebattery.




«ProgramSelect»Menudetail

Yourchargerisfeaturingausermemoryhandlingupto5customisedprograms.Youcansaveorrecalltheseprogramsatanytimebygettingin
thismenu.


Save
Tosaveaprogram,selectamemoryslotbetween1and5,thenvalidate.
Choosethebatterytype,thevoltageifnecessary,andthemaximumchargecapacity.
Press«Enter»during3seconds,a«*»symbolshouldblinkintoprightofthescreen.
PressEnterandselectthechargecurrent,andvalidateagain.
ForLithiumbatteries,pleasecheckthenumberofcellsandvalidate.
Then,pressagain“Enter”for3seconds,themessage“Save”willappearforafewinstants,theprogramisnow
savedinthechargermemory.

Load
Thisfunctionallowsyoutoloadapreviouslysavedprogram.Choosetheprogramnumberyouwishtoload,and
press«Enter»for3seconds.Youwillthenarrivetothebatterycharge/dischargeprogramyouhadrecordedin
thisprogram.
