X K 3 1 9 0 - A 9+
11
Order C
Tare，format：
14 units of data for each
a： symbol (+ or -)
b： Tare ( 6 bits）
： (from high to low)
g
h： decimal from right to left ( 0～4）
Order D
N.W，format：
14 units of data for each
a： symbol (+ or -)
b： N.W ( 6 bits ）
： (from high to low)
g
h： decimal from right to left ( 0～4）
Order E
Truck No.，format：
11 units of data for each
a： highest bit of Truck No.
b： second bit of Truck No.
： (from high to low)
e: lowest bit of Truck No.
Order F
Cargo No.，format：
14 units of data for each
a： highest bit of Cargo No.
b： second bit of Cargo No.
c： third bit of Cargo No.
Note 1: confirmation of XOR checking 4 bits of High and low: if it is ≤9, then to plus 30h,
and being ASCII to send. For example: if it is 6, plus 30h, then it equals 36h that is 6 in ASC
II code to send out; if it is ＞9, then plus 37h that will become a letter of ASCII to send
out. For example: it is B, plus 37h equals 42h that is B in ASCII to send out.
3. Upper monitor sending order list (set indicator communication address as 01):
Order type
Order definition
Upper monitor sending order (in hex)
A order
Handclasp 02 41 41 30 30 03
B order
Read G.W
02 41 42 30 33 03
C order
Read TARE
02 41 43 30 32 03
D order
Read N.W.
02 41 44 30 35 03
E order
Read N.W.
02 41 45 30 34 03
F order
Read N.W.
02 41 46 30 37 03
4. Setting of indicator communication parameter:
(1). Communication parameter
Communication parameter consists of communication address, baud rate, and
communication method.
(2) Communication parameter setting procedure:
Step
Operation display Note:
1 Press [Print
setting]
In weighing mode
