X K 3 1 9 0 - A 9+
3
Chapter One Technical Parameter
Model XK3190-A9+
Accuracy Class III, n=3000
Conversion
Δ－Σ type of A/D
Input signal range
-16 mV～ 18 mV
Conversion speed 10 times/second
A/D resolution code 1 million code
Calibration All operation made by keys
Excitation power DC, 5V, able to connect with 8pcs of 350Ω load cells or
16pcs of 700Ωload cells
Load cell connection
method
6 wire method, long wire auto compensation
Display 7 LED digit, 7 status indicating lights, 3 battery
indicating lights.
Display circulation 100ms
Division 1/2/5/10/20/50/100 optional
Clock Can display year/month/day, hour/minute/second,
auto reap year and moth
Number keys 0~9
Function keys 15 (10 of them are share with number keys for
combine application)
Material for keys Light touch type of pellicle
Scoreboard connection
interface
Serial output
Transmission method Current loop/ RS232 signal
Transmission data type 11 bytes
Baud rate 600
Transmission distance ≤30m
Serial communication interface
Transmission method RS232C/RS422(optional)/ RS485(optional)
Baud rate Baud rate option 600/1200/2400/4800/9600
