X K 3 1 9 0 –DS3
(7)
be ASCII code letter for sending, for example, Xor checking four higher bit is B. With 37h added, it is
42h, i.e. letter B in ASCII code for sending out.
3. Command list sent by host computer (set address of the indicator as 01):
Category
Content of Command
Host computer sends out commands (hexadecimal)
Command A
Hand shaking 02 41 41 30 30 03
Command B
Reading gross weight
02 41 42 30 33 03
Command C
Reading tare
02 41 43 30 32 03
Command D
Reading net weight
02 41 44 30 35 03
4. Indicator communication parameter setting:
(1). Communication parameters
Communication parameters are made up of three groups of parameters, i.e. communication address, baud
rate and communication method.
(2) Steps for setting communication parameters:
Step Operation Displayed content Note
1
Press [Parameter
setting]
In the weighing and
displaying state
2
Press [9][8]
Press [Input]
[ P 00 ]
[ P 98 ]
Input the setting password “98”
3
Press [1]
Press [Input]
[ Ad r ** ]
[ Ad r 01]
Address ( 01～26 )
E.g.: 1
4
Press [1]
Press [Input]
[ b t * ]
[ b t 1]
Baud rates of serial communication (0~4)
means following baud rates respectively:
600, 1200, 2400, 4800 and 9600 baud rates.
E.g.:1
5
Press [0]
Press [Input]
[ t F * ]
[ t F 0 ]
Way of serial communication:
0—Continuous send mode, no reception
1—Appointed answering mode
2—Old D2+ continuous communication
format, 8 bits every frame
3—New D2+ continuous communication
format, 9 bits every frame
（See Note 2）
E.g. 0
6 Weighing state Communication parameter setting is
completed
Note 2: In the old D2+ continuous communication format, data is output in form of ASC code with 8 Ⅱ
bits in every frame (including the decimal point). Lower bits of the data are sent at first and then
the higher ones. The frames are divided by “=”. Data being sent is the net weight (i.e. the value
displayed on indicator), for example, when the value 70.15 is displayed, the indicator
continuously sends out 51.0700＝51.0700＝51.0700…….
In the new D2+ (300 tons) continuous communication format, data is output in form of
ASC code with 9 bits in every frame (including the decimal point). Lower bits of the data are Ⅱ
sent at first and then the higher ones. The frames are divided by “=”. Data being sent is the net
weight (i.e. the value displayed on indicator), for example, when the value 70.15 is displayed,
the indicator continuously sends out 51.07000＝51.07000＝51.07000…...
Chapter 3 Operation Method
