PROAIM Sr. Pan Tilt Head - Attaching the Joystick Controller; Connect Power Supply; Connect Motor Cables; Connect Head Cables

7
Aaching the Joysck Controller
Aach 4-pin Power Cable with Joysck
Controller. Then aach other cables of
the motors with long cable.
The Pan Tilt Head circuitry is built enrely into the Joysck Controller. The only requirement is AC
Power pack (Included) or Baery Power. The power pack can handle 90-240 volts. Users will need
the appropriate plug adapter for local use.
Install 12 volt DC power (4 pin XLR) in
the socket of Joysck Box.
NOTE: Any 12 volt baery may operate
this Pan Tilt Head as long as the
Connector and the #1 Negave pin & #4
Posive pin of Cable meet together.
CAUTION: Do not use an unregulated power supply! If using a regulated power supply, it must
produce less than 12 volts. More than 24 volts may cause permanent damage.
 Aach the 4-pin male connector of
Cable to 4-pin female connector of Head
for Panning & Tilng.
(b)
(a)
