PROAIM Sr. Pan Tilt Head - Parts of Pan-Tilt Head; Setup & Adjustment; Mounting the Head

6
1. Gear for Tilng Movement
2. Gear for Panning Movement
3. 12v motor for Panning Movement
4. 12v motor for Tilng Movement
5. Adjustable Camera Plaorm
6. Base Plaorm for Tripod/ Jib Mounng
7. Joysck for pan/lt movement
8. On/O Switch
9. Pan Speed
10. Tilt Speed
 Aach Sr. Pan Tilt Head with jib
Mounng Plate. Align the screw
holes and ghten precisely to secure
the head.
Parts of Pan-Tilt Head
Setup & Adjustment of Pan Tilt Head
11. Pan Damping
12. Tilt damping
13. Pan Direcon
14. Tilt Direcon
15. 4 - Pin power out to Head
16. Fuse Holder
17. 12/24 V DC Input – 4 Pin XLR
1
15
9
8
11
13
7
14
12
10
17
16
5
6
3
2
4
