12
MOTOR INSTALLATION
• For easier set-up, prior to installing the motor, plug both the
hand pendant and Hi/Low motor cables into motor as shown.
WARNING:
NEVER use mattresses that DO NOT match the width (36”)
and length (80”) of the bed frame. Using mattresses that are
of smaller or larger dimensions may result in entrapment and
personal injury or death.
• Connect two 9V batteries (not included) to the battery clip
located on the motor. The battery clip is located in a recess
under the motor cover. With a charged battery installed, the
motor can be operated in the event of a power outage.
Figure 10 Figure 11
