Install the receiver antenna in the tube as shown. Do not
bend the end of antenna over the antenna tube and place
the cap over it or damage may result. The antenna does
not have to be outside of the tube to operate properly.
Keep the end of the antenna above the boat’s waterline
to get the best transmitter reception. Apply clear tape
(DYNM0102), if desired.
NOTICE: Do not cut or kink the receiver antenna or
damage may result.
Antenna Tube Installation
4
EN
River Jet
™
Transmitter Controls
Installing Transmitter Batteries
CAUTION: If using rechargeable batteries, charge
only rechargeable batteries. Charging non-
rechargeable batteries may cause the batteries to burst,
resulting in injury to persons and/or damage to property.
This transmitter requires 4 AA batteries.
1. Remove the battery cover from the transmitter.
2. Install the batteries as shown.
3. Install the battery cover.
CAUTION: Risk of explosion if battery is replaced by
an incorrect type. Dispose of used batteries
according to national regulations.
2.4GHZ DIGITAL
RADIO SYSTEM
1
2
11
3
4
8
7
9
6
10
5
12
1. Steering Wheel Controls direction (left/right) of the
model
2. Throttle Trigger Controls speed and direction (forward/
brake/reverse) of the model
3. ON/OFF Switch Turns the power ON/OFF
4. Throttle Limiting Switch Adjusts the throttle limit
from 50%, 75%, and 100%
5. TH Rate Adjusts the end point of the throttle
6. TH Trim Adjusts the throttle neutral point
7. TH REV Reverses the function of the speed control
when pulled back or pushed forward
8. ST REV Reverses the function of the steering when the
wheel is turned left or right
9. ST Trim Adjusts the steering center point
10. ST Rate Adjusts the end point of the steering
11. Antenna Transmits the signal to the model
12. Indicator Lights
• Solid red lights—indicates radio connectivity and
adequate battery power
• Flashing red lights—indicates the battery voltage
is critically low. Replace batteries
