3.2 Survey and construction
1
2
3
4
5
8
6
7
10
9
1. Handle
2. Lifting eye
3. Battery-adapter cable with terminals
4. Vacuum pump
5. Pressure gauge
6. Air filter
7. Chain box
8. Suction plate
9. Wheel Set VPH-RS, allow to use the device by one person (optionally)
10. Stop for Wheel Set VPH-RS-AS, for large-size tiles (optionally)
3.3 Technical data
Type
Carying capacity/WLL [kg] valve at 500 mbar under-pressure
Dead weight [kg]
VPH-150
150
19,5
