18
DA-2800 Operating Instructions V0.4
P18-FP
(1 subwoofer)
P815-FP
(1 speaker)
AND
1 P15-FP or 1 P10-FP
P610
(2 speakers)
PRESET 1 (Right)
1 2 3
PRESET 2 (Left)
1 2 3
Connect Link
Cable?
Input 2 to Input 3 Input 2 to Input 3 No
LINK Ch.1+Ch.2
On On On
LINK Ch.3+Ch.4
On Off On
INPUT Ch. 1
P18 P815 P610 (A)
INPUT Ch. 2
Link cable to 3 Link cable to 3 not used
INPUT Ch. 3
Link cable to 2 Link cable to 2 P610 (B)
INPUT Ch. 4
not used P15-FP or P10-FP not used
OUTPUT Ch. 1
P18 driver 1 -
Bridged
P815 Low Pass -Bridged
P610 (A)
Low Pass
OUTPUT Ch. 2
not used not used
P610 (A)
High Pass
OUTPUT Ch. 3
P18 driver 2-
Bridged
P815 HF
P610 (B)
Low Pass
OUTPUT Ch. 4
not used P15-FP or P10-FP
P610 (B)
High Pass
P6 or P8
(1 or 2 speakers)
AND
P15-FP or P10-FP
(1 or 2 subwoofers)
P610 (1 speaker)
AND
P6 or P8
(2 speakers)
P610 (1 speaker)
AND
P15-FP or P10-FP
(1 or 2 subs)
PRESET 1 (Right)
4 4 3
PRESET 2 (Left)
4 3 4
Connect Link
Cable?
No No No
LINK Ch.1+Ch.2
Off Off On
LINK Ch.3+Ch.4
Off On Off
INPUT Ch. 1
P6 or P8 (A) P6 or P8 (A) P610
INPUT Ch. 2
P6 or P8 (B) P6 or P8 (B) not used
INPUT Ch. 3
P10 or P15 (A) P610 P10 or P15 (A)
INPUT Ch. 4
P10 or P15 (B) - P10 or P15 (B)
OUTPUT Ch. 1
P6 or P8 (A) P6 or P8 (A)
P610
Low Pass
OUTPUT Ch. 2
P6 or P8 (B) P6 or P8 (B)
P610
High Pass
OUTPUT Ch. 3
P10 or P15 (A)
P610
Low Pass
P10 or P15 (A)
OUTPUT Ch. 4
P10 or P15 (B)
P610
High Pass
P10 or P15 (B)
