9.1.1 DC Supply, Outputs and Inputs
PIN No
DESCRIPTION
NOTES
1
DC Supply Input (Negative)
Negative DC Supply
2
DC Supply Input (Positive)
Positive DC Supply
3
Programmable Output
Battery Positive to drive a Relay
4
GCB
BatteryPositivetodriveaRelayforGenerator
5
Charging Alternator
Magnetisingcurrentduringstartingoftheengineis
deliveredtoChargingAlternator.Thecharging
Alternatorvoltageismeasuredhereandusedfor
disconnectingthecrankaswellasdetectingV-
Belt/ChargingAlternatorfailure.
6
MCB
BatteryPositivetodriveaRelayforMainsContactor
7
Solenoid
BatteryPositivetodriveaRelayforSolenoid
8
Crank
BatteryPositivetodriveaRelayforcrankingthe
9
Hooter
BatteryPositivetodriveaRelaytodrivehooter
duringfaultannunciation.
10
Ground
Ground pin
11
Comm. Driver
Return feed for sensor. Should be connected to the body
where sensor is mounted (Engine Body)
12
LLOP
Connect to Oil pressure sensor
13
HWT
Connect to High Water Temperature sensor
14
Fuel
Connect to Fuel sensor
15
MPU/W-Point
InputofMPUorW-Pointfromchargingalternator
9.1.2 Configurable Digital Inputs
PIN No
DESCRIPTION
NOTES
16
Digital Input 1
Switch to negative
17
Digital Input 2
Switch to negative
18
Digital Input 3
Switch to negative
19
Digital Input 4
Switch to negative
20
Digital Input 5
Switch to negative
21
Digital Input 6
Switch to negative
