4.2 Measurement
4.2.1 Generator
• 1 Phase / 3 Phase Voltage • 1 Phase / 3 Phase Current
• Frequency • PF, KW, KVA, KWH
• Water Temperature • Oil Pressure
• Fuel Level • RPM
• Run Hour • Service Due Hour
4.2.2 Mains
• 1 Phase/ 3 Phase Voltage • 1 Phase/ 3 Phase Current
• Frequency • PF
• KW • KVA
• Phase Sequence Detection • Voltage Unbalance
4.2.3 Mains Monitoring/ Mains Unhealthy condition
• Mains Under/Over Voltage • Mains Under Over Frequency
• Mains Unbalance Voltage • Mains Phase Sequence
4.2.4 Supervision
• Generator Under/Over Voltage • Generator Under/Over RPM
• Generator Current Unbalance • RWL
• Generator Overload: Both Current and KW • LLOP
• Charging Alternator/V-belt • Emergency off
• Service Due • Fail to Start
• Fail to Stop • Oil Level
• Canopy Temp • Fire
• HET/HWT • Oil Temperature
• Low Fuel
5.0. Digital Input & Output:
5.1 Digital Outputs
No of Digital Out Puts
6
Programmable Output
1
Could be assigned to any one of these functions
• None
• Unit Healthy
• Glow Plug/Choke.
• Fuel Pump
• Load Warning. This contact will get activated if the load
cross a defined level.
• MCCBShuntTrip.WhentheAutoshutdowninmanual
modeisselectedthisoutputcanbeusedtotripthe
MCCBandlettheengineshutdownonnoloadafter
coolingdown.
