ELECTRICAL CONNECTION
A15amp,120Volt,60Hzcircuitwithaproperlygroundedoutletisrequired.Preferably,the
replacewillbeonadedicatedcircuitasotherappliancesonthesamecircuitmaycausethecircuit
breakertotriporthefusetoblowwhentheheaterisinoperation.Plantheinstallationtoavoidthe
useofanextensioncord.Extensioncordsarefortemporaryuseonly.Ifanextensioncordmustbe
used,itmustbeUL/CSAcertied,ratedat10A(1250W),125Vmaximumwith16AWGminimum
andconstructedoftwocurrentcarryingconductorswithground.Aheavydutyextensioncordwith
theshortestlengthpossiblefortheconnectionisrecommendedandmustnotbelongerthan50ft.
(15.2m).Donotcoilorcovertheextensioncord.
Electricaloutletwiringmustcomplywithlocalbuildingcodesandotherapplicableregulationsto
reducetheriskofre,electricalshockandinjurytopersons.
Donotusethisreplaceifanypartofithasbeenunderwater.Immediatelycallaqualied
servicetechniciantoinspectthereplaceandreplaceanypartoftheelectricalsystemwhich
hasbeenunderwater.
GROUNDING INSTRUCTIONS
Thisheaterisforuseon120volts.ThecordhasaplugasshownatAinFig.20.Anadapteras
shownatCisavailableforconnectingthree-bladegrounding-typeplugstotwo-slotreceptacles.
Thegreengroundinglugextendingfromtheadaptermustbeconnectedtoapermanentground
suchasaproperlygroundedoutletbox.Theadaptershouldnotbeusedifathree-slotgrounded
receptacleisavailable.
Fig.20
OPERATING INSTRUCTIONS
Usingrockerswitch,turnbloweronandcheckforoperation.Turnonrockerswitchtothedesired
position.IntheMANpositionitwillremainconstantlyon.AUTOpositionwillbecontrolledbythe
temperaturesensor.TostoptheoperationturnrockerswitchtotheOposition.
GroundingPin
Adapter
GroundingMeans
MetalScrew
Coverof
Grounded
OutletBox
