4096-535
PRODELIN CORPORATION 3.8M C-BAND Rx/Tx ANTENNA SYSTEM
10
PART LIST - CONTINUED
ITEM NO. PART NO. DESCRIPTION QTY
20 8202-052 LOCKWASHER, 7/8” 12
21 8110-007 NUT, HEX 7/8” 12
22 8033-064 BOLT, 1/2 – 13 x 8.00 4
23 8033-072 BOLT, 1/2 – 13 x 9.00 4
24 8033-096 BOLT, 1/2 – 13 x 12.00 4
25 8201-033 FLATWASHER, 1/2” 12
26 8202-043 LOCKWASHER, 1/2” 12
27 0168-260 SPACER, 3.8M REFLECTOR LOCATOR 12
28 8032-014 BOLT, 3/8 – 16 x 1.75 32
29 8201-042 FLATWASHER, 3/8” 64
30 8202-042 LOCKWASHER, 3/8” 32
31 8102-007 NUT, HEX 3/8” 32
32 8036-016 BOLT, 1 – 8 x 2.00 2
33 8036-036 BOLT, 1 – 8 x 4.50 2
34 8036-040 BOLT, 1 – 8 x 5.00 2
35 8201-049 FLATWASHER, 1” 10
36 8202-046 LOCKWASHER, 1” 8
37 8107-007 NUT, HEX 1” 2
CAUTION: During the assembly procedure, the sequence of instructions must be
followed. Do Not Tighten Any Hardware Until Instructed. Refer to
the antenna assembly parts list and the following steps.
