prodelin 3.8M - Cross-Polarized and Co-Polarized Feed Types

4096-535
PRODELIN CORPORATION 3.8M C-BAND Rx/Tx ANTENNA SYSTEM
22
4.2 C-BAND CROSS-POL AND CO-POL FEEDS
Prodelin 3.8m Rx/Tx antenna system is available in Cross-pol, or Co-pol feed
assemblies with type "N" or "WR137" connectors. Refer to figure 6, the parts list
for this section and follow the instructions in the listed sequence.
C-BAND CROSS-POL & CO-POL FEED PARTS LIST
ITEM # PART # DESCRIPTION QTY
0800-276 FEED ASSEMBLY, CO-POL, TYPE N
1 0800-178 FEED ASSEMBLY, CO-POL, TYPE WR137 1
0800-277 FEED ASSEMBLY, CROSS-POL, TYPE N
0800-179 FEED ASSEMBLY, CROSS-POL, TYPE WR137
2 0211-420 FEED MOUNTING BRACKET, BOTTOM 1
3 0211-419 FEED MOUNTING BRACKET, TOP 1
4 8032-010 BOLT, 3/8-16 x 1.25" 4
5 8202-042 LOCKWASHER, 3/8" 4
6 8102-007 NUT, HEX, 3/8-16 4
7 8031-008 BOLT, 5/16-18 x 1.00" 2
8 8202-041 LOCKWASHER, 5/16" 2
9 8101-009 NUT, HEX, 5/16-18 2
