prodelin 3.8M - Page 28

4096-535
PRODELIN CORPORATION 3.8M C-BAND Rx/Tx ANTENNA SYSTEM
26
Small Opening
( 2.75 Dia )
[ 1 ]
Feed Support
Feed Rod
[ 4 ]
[ 9, 11, 12 ]
[ 3 ]
[ 10, 11, 12 ]
[ 2 ]
[ 6, 7, 8 ] 2 PL
[ 5, 8 ]
2 PL
Receive
Transmit
OMT
POLARIZER
WR137
Figure 7
