4096-535
PRODELIN CORPORATION 3.8M C-BAND Rx/Tx ANTENNA SYSTEM
32
Figure 10
Inclinometer
Upright:
(reading + 22.620 =
elevation look angle)
Inverted
(reading – 22.620 =
elevation look angle)
Remove 1” Hardware for
Azimuth Adjustment
Elevation
Adjustment
Azimuth
Adjustment
