PRODEM PHC 050 - Page 12

- 12 -
Model PHC 200 PHC 300
Impulse Force
t
onne
(
klbs)
11.2
(24.7)
17.3
(38.1)
Weight
1)
Adapter mount type(N*) kg (lbs)
Adapter mount type(G*) kg (lbs) 1,094 (2,412) 1,502 (3,312)
D
irect mount type (N*)
kg
(lbs)
Direct mount type (G*) kg (lbs)
Height (H)
1)
A
dapter mount type(N*)
mm
(
in.)
Adapter mount type(G*) mm (in.) 840 (33.1) 943 (37.1)
Direct mount type (N*) mm (in.)
Direct mount type (G*) mm (in.)
Width (W) (N*) mm
(
in.)
Width (W) (G*) mm (in.) 860 (33.9) 1,000 (39.4)
Base Plate
Dimensions (W x L) (N*) mm
(
in.)
Dimensions (W x L) (G*) mm (in.) 860 x 1,200 (33.9 x 47.2) 1,000 x 1,300 (39.4 x 51.2)
Compaction Area (N*) m
2
(ft
2
)
Compaction Area (G*) m
3
(ft
3
) 1.03 (11.1) 1.30 (14.0)
Oil Flow
with 'N' type valve lpm (gpm) 110 ~ 162 (29.1 ~ 42.8) 160 ~ 220 (42.3 ~ 58.1)
with 'P' type valve
2)
lpm (gpm) 110 ~ 200 (29.1 ~ 52.8) 160 ~ 250 (42.3 ~ 66.0)
Max. Cycles Per Minute rpm 2,000 2,000
Operating Pressure
F
ree load
bar
(psi)
3
0 ~ 50
(440 ~ 730)
3
0 ~ 50
(440 ~ 730)
With load bar (psi) 100 ~ 138 (1,450 ~ 2,000) 100 ~ 138 (1,450 ~ 2,000)
Recommended Carrier tonne (ton) 17 ~ 25 (19 ~ 28) 26 ~ 40 (29 ~ 44)
Weight
Recommended Hydraulic mm (in.) 25 (1) 32 (1-1/4)
Line Size (In / Out)
Max. Acceptable Back bar (psi) 15 (220) 15 (220)
Pressure
Max. Pressure Relief bar (psi) 138 (2,000) 138 (2,000)
Type of Hose Connection Ports
BSP
1
O-Ring Boss Female
BSP
1-1/4
O-Ring Boss Female
(JIS B2351 Type 'O')
(JIS B2351 Type 'O')
Available Fitting Set ORFS -16
3)
ORFS -20
3)
B
SP
1
(
60
º Cone
)
4)
B
SP
1
-
1
/
4
(
60
º Cone
)
4)
JIC -16
5)
JIC -20
5)
Notes: 1) Excluding mounting adapter, hydraulic hoses, fittings and mounting pins.
2) Standard settings at the factory. Other extra flow ranges are also available on request.
3) The O-Ring Face Seal (ORFS) type hose coupling according to SAE J1453
4) The 60º cone type hose coupling according to JIS B8363 (hoses with 60º male sealing face)
5) The 37º flare type hose coulping according to SAE J514
6) PHC 050: (N*)-Narrow type, (G*)-General type
