PRODEM PHC 050 - Specifications

- 11 -
2.3. Specifications
 Adapter Mount Type  Direct Mount Type
L
H
W
'P' Port
(IN)
'T' Port
(OUT)
L
W
H
'T' Port
(OUT)
'P' Port
(IN)
Figure 10 Figure 11
Model PHC 050 PHC 100 PHC 150
Impulse Force
t
onne
(
klbs)
2.1
(4.6)
4.0
(8.8)
6.4
(14.1)
Weight
1)
A
dapter mount type(N*)
kg
(lbs)
260
(573)
A
dapter mount type(G*)
kg
(lbs)
280
(617)
430
(948)
689
(1,519)
D
irect mount type (N*)
kg
(lbs)
264
(582)
D
irect mount type (G*)
kg
(lbs)
344
(759)
Height (H)
1)
A
dapter mount type(N*)
mm
(
in.)
650
(25.6)
A
dapter mount type(G*)
mm
(
in.)
675
(26.6)
640
(25.2)
750
(29.5)
Direct mount type
(N*)
mm
(in.)
695
(27.4)
Direct mount type
(G*)
mm
(in.)
720
(28.3)
Width (W) (N*) mm
(
in.)
320
(12.6)
Width (W) (G*) mm
(
in.)
500
(19.7)
610
(24.0)
740
(29.1)
Base Plate
Dimensions (W x L) (N*) mm
(
in.)
320
x
745
(12.6 x 29.3)
Dimensions (W x L) (G*) mm
(
in.)
500
x
800
(19.7 x 31.5)
6
1
0
x
90
0
(24.0 x 35.4)
740
x
1,05
0
(29.1 x 41.3)
Compaction Area (N*)
m
2
(
ft
2
)
0.24
(2.6)
Compaction Area (G*)
m
3
(
ft
3
)
0.40
(4.3)
0.55
(5.9)
0.78
(8.4)
Oil Flow
w
ith 'N' type valve
l
pm
(gpm)
5
0 ~
72
(13.2 ~ 19.0)
80
~
116
(21.1 ~ 30.6)
w
ith 'P' type valve
2)
l
pm
(gpm)
45
~
65
(11.9 ~ 17.2)
5
0 ~
120
(13.2 ~ 31.7)
80
~
170
(21.1 ~ 44.9)
Max. Cycles Per Minute
r
pm
2,100
2,000
2,000
Operating Pressure
F
ree load
bar
(psi)
3
0 ~ 50
(440 ~ 730)
3
0 ~ 50
(440 ~ 730)
3
0 ~ 50
(440 ~ 730)
With load bar (psi) 100 ~ 220 (1,450 ~ 3,190) 100 ~ 138 (1,450 ~ 2,000) 100 ~ 138 (1,450 ~ 2,000)
Recommended Carrier
t
onne
(ton)
4 ~ 6
(4 ~ 7)
6 ~ 10
(7 ~ 11)
1
1
~
16
(12 ~ 18)
Weight
Recommended Hydraulic mm
(
in.)
12.7
(1/2)
19
(3/4)
19
(3/4)
Line Size (In / Out)
Max. Acceptable Back bar (psi) 15 (220) 15 (220) 15 (220)
Pressure
Max. Pressure Relief bar (psi) 220 (3,190) 138 (2,000) 138 (2,000)
Type of Hose Connection Ports
BSP
1/2
O-Ring Boss Female
BSP
3/4
O-Ring Boss Female
BSP
3/4
O-Ring Boss Female
(JIS B2351 Type 'O')
(JIS B2351 Type 'O')
(JIS B2351 Type 'O')
Available Fitting Set
O
RFS -8
3)
O
RFS -12
3)
O
RFS -12
3)
B
SP 1/2 (60º Cone)
4)
B
SP 3/4 (60º Cone)
4)
B
SP 3/4 (60º Cone)
4)
J
IC -8
5)
J
IC -12
5)
J
IC -12
5)
