5.5. Tightening torques
Fastening parts of the compactor should be tightened at the specified torque and applying the specified
screw sealant.
Remember that loose bolts will result in not only damages to bolts but also serious damage to the concerned
parts.
When tightening bolts, be sure to follow the tightening instruction described in section 5.4.
PARTS MODELS
DIMENSION
Thread / Hex
TIGHTENING
TORQUES [N

M]
REMARKS
Housing & cover bolts
PHC050
PHC100, PHC150
PHC 200
PHC 300
M10 / 8 wrench
M10 / 17
M16 / 24
M22 / 32
70 +10
70 +10
280 +30
750 +80
Apply the thread-
locking adhesive.
(Loctite 271, 272
or equivalent)
Cushion plate bolts
(cushion rubber)
PHC 050, PHC 100
,
PHC 150
PHC 200, PHC 300
M12 / 19
M18 / 30
120 +20
460 +60
Motor fixing bolts
PHC 050, PHC 100
,
PHC 150, PHC 200
PHC 300
M12 / 19
M16 / 24
120 +20
270 +30
Motor control valve
fixing bolt
PHC 050
PHC 100, PHC 150
PHC 200, PHC 300
M8 / 13
M12 / 19
M16 / 24
35 +5
100 +20
280 +30
Mounting adaptor
fixing bolt
PHC 100, PHC 150
PHC 200
PHC 300
M20 / 30
M30 / 46
M36 / 55
600 +60
1900 +200
3300 +300
For adaptor mount
type only
