14
Connect the 3/8in black tubing from the
water supply to the inline lter at the ball
valve. Cut to length.
Flush the lter into the drain for 2 minutes.
FLUSH THE CITY WATER LINE FOR
3-4 MINUTES BEFORE CONNECTING
TO OUR WATER LINE.
Thread black tubing
(water inlet and drain kit)
Run the drain line to the oor drain. Cut to
length.
Strap the 3/8in black tubing to the existing
drain lines using zip ties.
Leave 1in air gap between the 3/8in black
tubing and the drain to avoid contamination.
Connect 3/8in black tubing to the mist
control box port labeled “DRAIN”.
Connect the inline lter to the mist control
box port labeled “WATER INLET”.
System Installation
23 24 25
22
2726
Fill all voids around the corrugated tubing
with silicone to avoid leaks.
To Next Page
