When the audio inputs are configured as MIC level inputs, sensibility range is –
60dBu to –20dBu.
When phantom power is enabled, the whole gain is decreased by 15
dB to compensate for the higher output of condenser MICs. Thus,
the gain range will go from –45 to –5dBu.
When the inputs are configured as LINE level inputs, the maximum input level
will be +20dBu.
In order to better adapt to different kinds of microphones, the Gain PAD option
in the microphones configuration permits to subtract 18 dB to the microphone
gain.
The audio level control can be achieved locally or remotely by using the
Quantum W web interface. Once the audio input gain setting has been selected
to be controlled by remote control, the Quantum Portable reminds this effect on
its touch panel upon any attempt to increase or decrease the audio gains locally
by means of the audio control knobs, with the message “Gain controls are
remotely controlled”.
For more information about how to control the level controls of the audio input
please refer to chapter II.4.1.
