TECHNICAL SPECIFICATIONS
V.1 Audio Interfaces
V.1.1 IN1 – IN3 inputs in MIC MODE
Parameter
Value
Conditions
Max. Input Level
-46 dBu
 knob to 0 dB Gain, no compressor enabled.
 150Ω microphone.
 The max input level is for 0 dBFs.
Input stage gain
tolerance
±0.5 dB
Frequency response
-0.3dB
 20Hz-20 kHz
Phase difference
<±3º
 20Hz-20 kHz
 Input 2 to input 3 and input 4 to input 5
 -47 dBu 997Hz test signal
Crosstalk
>80 dB
Max Input referred noise
<-116
dBqps
 knob to 0 dB Gain, no compressor enabled.
 200Ω microphone.
 Measured 22Hz to 20 kHz
THD+N Ratio
> 75 dB
< 0.02%
 knob to 0 dB Gain, no compressor enabled.
 150Ω microphone.
 Measured 22Hz to 20 kHz.
 -47 dBu 997Hz test signal
THD
< 0.01%
 Measured with Tektronix AM700.
 Excludes noise contribution
Max input impedance
2 kΩ
 differential
Phantom Power
+48V
 switchable
Compressor ratio
1:3

Compressor Knee
-7.5 dBFs
 hard knee
THD+N Ratio
<0.1%
 150Ω microphone.
 Measured 22Hz to 20 kHz
 From knee to clipping
 XLR connectors.
 Maximum levels:
o LINE levels: +20dBu.
o MIC levels: -46dBu (without compressor).
o MIC levels: -33dBu (with compressor).
