 Input impedance:
o LINE mode = 24Kohm.
o MIC mode = 4Kohm.
 Mic input sensitivity adjustable from -25 to -65 dBu.
 THD+N < 0.02% (MIC mode), 0.005% (LINE mode). @ 1kHz.
 SNR > 75dB (MIC mode), 95dB (LINE mode).
 Phantom power (48 Volts).
V.1.2 IN1 – IN3 inputs in LINE MODE
Parameter
Value
Conditions
Max. Input Level
+20 dBu
 knob to 0 dB Gain, no compressor enabled.
 40Ω line driver.
 Measured 22Hz to 20 kHz
Input stage gain
tolerance
±0.5 dB
Frequency response
-0.3dB
 20Hz-20 kHz
Phase difference
<±3º
 20Hz-20 kHz
 Input 2 to input 3 and input 4 to input 5
 -47 dBu 997Hz test signal
Crosstalk
>90 dB
Noise Level
<-94 dBFs
 knob to 0 dB Gain, no compressor enabled.
 40Ω line driver.
 Measured 22Hz to 20 kHz
THD+N Ratio
> 93 dB
< 0.005%
 knob to 0 dB Gain, no compressor enabled.
 40Ω line driver.
 Measured 22Hz to 20 kHz.
 19 dBu 997Hz test signal
Max input impedance
24 kΩ
 differential
Phantom Power
+48V
 switchable
Compressor ratio
1:3
Compressor Knee
-7.5 dBFs
 hard knee
THD+N Ratio
<0.1%
 200Ω microphone.
 Measured 22Hz to 20 kHz
 From knee to clipping
