• AUX RCA stereo CD/TAPE/TUNER input with selectable
sensitivity.
• Four discrete outputs. Constant impedance output (4Ω) and three
constant voltage outputs (25V - 70 V – 100 V).
• PRE OUT output.
• TAPE OUTPUT.
• Switchable power supply (115V – 230 V).
• Emergency 24 V DC power supply.
3. FRONT PANEL DESCRIPTION
fig.1
8) POWER switch.
9) MASTER volume control.
10) TREBLE EQ control.
11) BASS EQ control.
12) LED power indicator.
13) INPUT1 - INPUT5 volume controls.
14) OUTPUT LED Vu-meter.
