PROEL LIGHTING LED - Page 27

27
Ceiling Projectors
CEILING-MOUNT LED COLOUR CHANGING SYSTEM
Input Voltage: 110 / 220V AC, 50/60Hz
86 LEDs: 28 R, 28 G, 30 B - Ø5mm
Protocol: DMX512 - 4 channels
Operation modes: built-in programs, Master/slave.
Max. Power Consumption: 6W
CEILING-MOUNT LED COLOUR CHANGING SYSTEM HIGH POWER
Input Voltage: 110 / 220V AC, 50/60Hz
18 LEDs: 6 R, 6 G, 6 B
Protocol: DMX512 - 4 channels
Operation modes: built-in programs, Master/slave.
Max. Power Consumption: 18W
Splitter for 8 PLLEDCL (230V 50Hz) Splitter for 6 PLLEDCLHP (230V 50Hz)
4 channels DMX
4 channels DMX
Power: 24 VDC
LED: 86: 28R - 28G - 30B
Size: mm. 199L x 168W x 199H
Weight: 1.2 Kgs
Power: 24 VDC
LED: 18: 6R - 6G - 6B
Size: mm. 199L x 168W x 199H
Weight: 1 Kgs
PLLEDCL
PLLEDCLHP
PLLEDCNTR PLLEDCNTRHP
