LED Bars
RGB LINEAR WASHER
RGB Linear Washer with full colour technology and high power 3W LEDs.
In order to meet any requirement, we designed four versions in diff erent
sizes: 100 cm with 8 LEDs, 75 cm with 6 LEDs, 50 cm with 4 LEDs, and 25 cm
with 2 LEDs.
Particularly suited for linear fl ood lighting in clubs, pubs and entertainment
venues in general.
Three diff erent beam apertures available: Wide – Medium – Narrow.
DMX remote controller
Max 6 channels
DMX controller, 3 output costant current , or voltage in PWM max 1A @24vdc
Each output is controllable by DMX optoinsulated ,this feature guarantee
,noise rejection and very stable signal receiveing .
DMX setting is self learning , just pushing the button DMXSET the red led
indicate self-learning active mode.
The harness is made by male and female connector for input / output DMX
and power supply .
INPUT ELECTRICAL SPECS:
Input voltage range: 10-28 Vdc
Max power consumption: 74W
OUTPUT ELECTRICAL SPECS:
Common anode
Max power output per channel: 24W
Output current per channel: 1A
Costant current PWM
Controller:
max 1 PLLEDWS8
max 2 PLLEDWS6
max 3 PLLEDWS4
max 6 PLLEDWS2
7 channels DMX
Power: Via PLLEDC289A
LED: 8 RGB full colour 3W
Size: mm. 1000L x 40W x 100H
Weight: 10 Kgs
Power: Via PLLEDC289A
LED: 6 RGB full color 3W
Size: mm. 750L x 40W x 100H
Weight: 7 Kgs
Power: Via PLLEDC289A
LED: 4 RGB full color 3W
Size: mm. 500L x 40W x 100H
Weight: 4 Kgs
Power: Via PLLEDC289A
LED: 2 RGB full color 3W
Size: mm. 250L x 40W x 100H
Weight: 2 Kgs
