PROEL LIGHTING LED - Page 39

39
LED Bars
Power supply: via PLLEDC2091 (max. 4 bars for each PLLEDC2091)
Rated Power: 11W
LED: 9 1.2W White LEDs (Cree LEDs)
Lens: 30° (12°, 45° and elliptical lenses available)
Aluminium body
Connection to PLLEDC2091 with CAT5 cable
IP rating: IP20
This unit complies with CE directives
The PLLEDLB9W30 (5500K) is a high power white LED Bar.
It is designed for indoor use, especially for wall lighting applications in
pubs, cafés or any other small premises requiring high power lighting.
Power supply: via PLLEDC2091 (max. 4 bars for each PLLEDC2091)
Rated Power: 11W
LED: 9 1.2W RGB LEDs (3R – 3G – 3B – Cree LEDs)
Lens: 30° (12°, 45° and elliptical lenses available)
Aluminium body
Connection to PLLEDC2091 with CAT5 cable
IP rating: IP20
This unit complies with CE directives
The PLLEDLB930 is a high power LED Colour Changing Bar.
It is designed for indoor use in pubs, cafés or any other small premises
requiring high power lighting.
1
0.28
2
0.56
3
0.84
4
1.12
5
1.41
2866LUX 5500K
Distance (m)
Diameter X (m)
0.49 0.78 1.07 1.36 1.65Diameter Y (m)
717 318 179 115
50%
100%
50%
30° LENSES
16°
x
20°
RED lux = 39% of maximum light
GREEN lux = 46% of maximum light
BLUE lux = 15% of maximum light
CYAN lux = 61% of maximum light
MAGENTA lux = 54% of maximum light
YELLOW lux = 85% of maximum light
1
0.28
2
0.56
3
0.84
4
1.12
5
1.41
1015LUX full on
Distance (m)
Diameter X (m)
0.52 0.83 1.15 1.47 1.79Diameter Y (m)
254 113 63 41
50%
100%
50%
30° LENSES
16°
x
24°
Power : Via PLLEDC2091
LED: 9 WHITE - 1,2W
Size: L331xW49xH35 mm
Weight: 3 Kgs
Power : Via PLLEDC2091
LED: 9 RGB - 1,2W - (3R - 3G - 3B)
Size: L331xW49xH35 mm
Weight: 3 Kgs
PLLEDLB9W30PLLEDLB930
