PROEL LIGHTING LED - Page 44

44
Connections
Connection mini led projectors RGB
Connection led bar 8 led RGB
Connection led bar 6 led RGB
Connection led bar 4 led RGB
Connection led bar 2 led RGB
PLLEDC243
outputpower in
DMX
DMX controller
PLLEDCL3FRGB PLLEDCL3FRGB PLLEDCL3FRGB PLLEDCL3FRGB
1 2 3 max 4 pcs
PLLEDC243
output
PLLEDCL3RGB
1 2 max 12 pcs
PLLEDCL3RGB PLLEDCL3RGB
power in
DMX
DMX controller
PLLEDWS2
IN OUT
PLLEDWS2
IN OUT
PLLEDWS2
IN OUT
RED
GREEN
BLUE
- V
+V
TRAFO
24Vdc - 2,3A
PLLEDC289A
DMX
GENERATOR
V+
V-
MAX 4 pcs.
PLLEDWS2
IN OUT
PLLEDWS4
IN OUT
PLLEDWS4
IN OUT
PLLEDWS4
IN OUT
RED
GREEN
BLUE
- V
+V
TRAFO
24Vdc - 2,3A
PLLEDC289A
DMX
GENERATOR
V+
V-
MAX 3 pcs.
PLLEDWS6
IN OUT
PLLEDWS6
IN OUT
RED
GREEN
BLUE
- V
+V
TRAFO
24Vdc - 2,3A
PLLEDC289A
DMX
GENERATOR
V+
V-
MAX 2 pcs.
PLLEDWS8
IN
RED
GREEN
BLUE
- V
+V
TRAFO
24Vdc - 2,3A
PLLEDC289A
DMX
GENERATOR
V+
V-
MAX 1 pc
