TECHNICAL SPECIFICATIONS SPECIFICHE TECNICHE
Section Levels & Data Connectors
MONO INPUT CHANNEL
Mic Input
sensitivity from 0 to -60 dB
Balanced XLR-F
impedance 2 Kohm
Line Input
sensitivity from +20 to -40 dB
Balanced Jack
impedance 10 Kohm
EQ
HIGH ±15 dB @ 12 KHz shelving
MID ±15 dB peaking
FREQ 100 Hz ÷ 8 KHz Q=1.8
LOW ±15 dB @ 80 Hz shelving
STEREO INPUT CHANNEL
Mic Input
sensitivity from 0 to -40 dB
Balanced XLR-F
impedance 2 Kohm
Line Input
sensitivity from +20 to -20 dB
Balanced Jack
impedance 10 Kohm
EQ
HIGH ±15 dB @ 12 KHz shelving
HI MID ±15 dB @ 3 KHz peaking
LO MID ±15 dB @ 500 KHz peaking
LOW ±15 dB @ 80 Hz shelving
MASTER SECTION
MAIN MIX nom. out level +4 dBu Balanced Jack
GROUP 1-2 nom. out level +4 dBu Balanced Jack
C. ROOM output nom. out level +4 dBu Unbalanced Jack
AUX 1 OUT nom. out level +4 dBu Unbalanced Jack
AUX 2 OUT nom. out level +4 dBu Unbalanced Jack
AUX 3 OUT nom. out level +4 dBu Unbalanced Jack
2-TRK
nom. out level 0 dBu Unbalanced Rca
nom. in level -10 dBv Unbalanced Rca
HEADPHONES
min. impedance 32 ohm
Stereo Jack
max. out level (2x) 193 mW
DIGITAL EFFECT PROCESSOR
Presets HALL, ROOM, VOCAL and PLATE reverbs
STEREO, MONO and TAP delays
CHORUS and FLANGER modulations
REV + STEREO DELAY, REV + MONO DELAY,
REV +CHORUS and REV + FLANGER combinations
Variations Each Preset has 16 parameter variations
Controls MUTE switch, TAP switch, MUTE pedal, TAP pedal
USB INTERFACE
Version Fully compliant with USB 1.1
Resolution 16-Bit Delta Sigma ADC and DAC
Sampling Rate DAC: 32, 44.1, 48 kHz
ADC: 8, 11.025, 16, 22.05, 32, 44.1, 48 kHz
GENERAL SPECIFICATIONS
Maximum level all outputs +22 dBu
Crosstalk meas. at 1 KHz > 82 dBu
HUM & Noise unweighted < -93 dBu
THD + Noise at +4dB, 1kHz < 0,008 %
Weight 6.5Kg
Dimensions (WxHxD) 48.5 x 9 x 43.5 cm
Sezione Livelli e Dati Connettori
CANALE INGRESSO MONO
Ingresso Mic
sensibilità da 0 a -60 dB
XLR-F Bilanciato
impedenza 2 Kohm
Ingresso Line
sensibilità da +20 a -40 dB
Jack Bilanciato
impedenza 10 Kohm
EQ
ALTI ±15 dB @ 12 KHz shelving
MEDI ±15 dB @ 2.5 KHz peaking
FREQUENZA 100 Hz ÷ 8 KHz Q=1.8
BASSI ±15 dB @ 80 Hz shelving
CANALE INGRESSO STEREO
Ingresso Mic
sensibilità da 0 a -40 dB
XLR-F Bilanciato
impedenza 2 Kohm
Ingresso Line
sensibilità da +20 a -20 dB
Jack Bilanciato
impedenza 10 Kohm
EQ
ALTI ±15 dB @ 12 KHz shelving
MEDIO ALTI ±15 dB @ 3 KHz peaking
MEDIO BASSI ±15 dB @ 500 Hz peaking
BASSI ±15 dB @ 80 Hz shelving
SEZIONE MASTER
MAIN MIX liv. nom. uscita +4 dBu Jack Bilanciato
GROUP 1-2 liv. nom. uscita +4 dBu Jack Bilanciato
C. ROOM output liv. nom. uscita +4 dBu Jack Sbilanciato
AUX 1 OUT liv. nom. uscita +4 dBu Jack Sbilanciato
AUX 2 OUT liv. nom. uscita +4 dBu Jack Sbilanciato
AUX 3 OUT liv. nom. uscita +4 dBu Jack Sbilanciato
2-TRK
liv. nom. uscita 0 dBu Rca Sbilanciato
liv. nom. ingr. -10 dBv Rca Sbilanciato
HEADPHONES
impedenza min. 32 ohm
Jack Stereo
uscita massima (2x) 193 mW
DIGITAL EFFECT PROCESSOR
Preset riverberi HALL, ROOM, VOCAL e PLATE
delay STEREO, MONO e TAP
modulazioni CHORUS e FLANGER
combinazioni REV + STEREO DELAY, REV + MONO DELAY,
REV +CHORUS e REV + FLANGER
Variazioni Ogni preset ha 16 variazioni di parametri
Controlli tasto MUTE, tasto TAP, pedale MUTE, pedale TAP
INTERFACCIA USB
Versione Completamente compatibile con speci che USB 1.1
Risoluzione 16-Bit Delta Sigma ADC e DAC
Frequenza di
campionamento
DAC: 32, 44.1, 48 kHz
ADC: 8, 11.025, 16, 22.05, 32, 44.1, 48 kHz
SPECIFICHE GENERALI
Livello Massimo tutte le uscite +22 dBu
Diafonia mis. a 1 KHz > 82 dBu
Ronzio e Rumore non pesato < -93 dBu
THD + Rumore a +4dB, 1kHz < 0,008 %
Peso 6,5 Kg
Dimensioni (LxAxP) 48,5 x 9 x 43,5 cm
