PROEL M1622USB User Manual

5
MODEL M1622USB Connectors MODELLO M1622USB Conne ori
MONO INPUT CHANNELS CANALI INGRESSO MONO
Mic Input Sensi vity from 0 to -60 dBu
Balanced XLR-F
Sensibilità Ingresso Mic da 0 a -60 dBu
XLR-F Bilanciato
Mic Input Impedance 2 Kohm Impedenza Ingresso Mic 2 Kohm
Line Input Sensi vity from +20 to -40 dBu
Balanced Jack
Sensibilità Ingresso Line da +20 a -40 dBu
Jack Bilanciato
Line Input Impedance 10 Kohm Impedenza Ingresso Line 10 Kohm
LO CUT 75Hz, 18dB/oct. FILTRO LO-CUT 75Hz, 18dB/oct.
EQ HIGH (shelving) ±15 dB @ 12KHz EQ ALTI (shelving) ±15 dB @ 12KHz
EQ MID (peaking) ±15 dB @ 2.5KHz from 100 Hz to 8 KHz EQ MEDI (peaking) ±15 dB @ 2.5KHz da 100 Hz a 8 KHz
EQ LOW (shelving) ±15 dB @ 80Hz EQ BASSI (shelving) ±15 dB @ 80Hz
STEREO INPUT CHANNELS CANALI INGRESSO STEREO
Mic Input Sensi vity from 0 to -40 dBu
Balanced XLR-F
Sensibilità Ingresso Mic da 0 a -40 dBu
XLR-F Bilanciato
Mic Input Impedance 2 Kohm Impedenza Ingresso Mic 2 Kohm
Line Input Sensi vity from +20 to -20 dBu
Balanced Jack
Sensibilità Ingresso Line da +20 a -20 dBu
Jack Bilanciato
Line Input Impedance 10 Kohm Impedenza Ingresso Line 10 Kohm
EQ HIGH (shelving) ±15 dB @ 12 KHz EQ ALTI (shelving) ±15 dB @ 12KHz
EQ HI-MID (peaking) ±15 dB @ 3 KHz EQ MEDIO-ALTI (peaking) ±15 dB @ 3 KHz
EQ LO-MID (peaking) ±15 dB @ 500 Hz EQ MEDIO-BASSI (peaking) ±15 dB @ 500 Hz
EQ LOW (shelving) ±15 dB @ 80Hz EQ BASSI (shelving) ±15 dB @ 80Hz
MASTER SECTION SEZIONE MASTER
MAIN MIX nom. out level +4 dBu Balanced Jack / XLR-M Livello nom. MAIN MIX +4 dBu Jack Bilanciato / XLR-M
MAIN MIX INSERT 0 dBu TRS Jack INSERT MAIN MIX 0 dBu TRS Jack
MIX/AUX Assignable EQ graphic 7 band MIX/AUX EQ Assegnabile graphic 7 band
GROUP nom. out level +4 dBu Balanced Jack Livello nom. GROUP +4 dBu Jack Bilanciato
C.ROOM nom. out level 0 dBu Unbalanced Jack Livello nom. C.ROOM 0 dBu Jack Sbilanciato
AUX nom. out level 0 dBu Unbalanced Jack Livello nom. AUX 0 dBu Jack Sbilanciato
2 - TRK nom. out level 0 dBu Unbalanced Rca Livello nom. 2 - TRK OUT 0 dBu Rca Sbilanciato
2 - TRK nom. in level 0 dBu Unbalanced Rca Livello nom. 2 - TRK IN 0 dBu Rca Sbilanciato
PHONES min. impedance 32 ohm
Stereo Jack
Impedenza min. PHONES 32 ohm
Jack Stereo
PHONES max. out level (2x) 193 mW Livello max. PHONES (2x) 193 mW
USB IN/OUT, 16bit / 48KHz
Type B
USB IN/OUT, 16bit / 48KHz
Tipo B
DIGITAL EFFECT PROCESSOR - PROFEX DIGITAL EFFECT PROCESSOR - PROFEX
Presets 256 (16 presets x 16 varia ons) Presets 256 (16 preset x 16 variazioni)
A/D and D/A converters 24 bit A/D and D/A converters 24 bit
DSP resolu on 24 bit DSP resolu on 24 bit
Controls 2-digit display, PRESET dial, PEAK LED, TAP DELAY
and MUTE with switch, footswitch and LED
Controlli 2 display LED, sele ore PRESET, PEAK LED, TAP
DELAY e MUTE con tasto, pedale e LED
GENERAL SPECIFICATIONS SPECIFICHE GENERALI
Max level all outputs +22 dBu Livello Massimo Uscite +22 dBu
Crosstalk meas. at 1 KHz > 82 dB Diafonia mis. a 1 KHz > 82 dB
HUM & N unweighted < -93 dBu HUM & N non pesato < -93 dBu
THD+N at +4dB, 1kHz < 0,008 % THD+N a +4dB, 1kHz < 0,008 %
Dimensions (W x H x D) 465 x 91 x 462 mm Dimensioni (L x A x P) 465 x 91 x 462 mm
Weight 6.50 kg Peso 6,50 kg
POWER REQUIREMENTS ALIMENTAZIONE
Mains Supply Voltage: 110-240 VAC (±10%) 50 / 60 Hz
available with Europe mains cord (Shucko plug),
US mains cord (NEMA 5-15P plug),
UK mains cord (BS1363 plug)
Tensione di Rete: 110-240 VAC (±10%) 50 / 60 Hz
disponibile con cavo rete Europa (spina Shucko),
cavo rete Sta Uni (spina NEMA 5-15P),
cavo rete Regno Unito (spina BS1363)
Consump on 75 W Assorbimento 75 W
TECHNICAL SPECIFICATIONS SPECIFICHE TECNICHE
