(2 ﺩﻋﺎﺳﻣ ﺱﺑﺎﻗ ﻝﺧﺩﻣ) AUX SEND 2 .47
ﻝﺧﺩ ﻝﻳﺻﻭﺗﻟ ﺓﺩﺎﻋ ﻡﺩﺧﺗﺳ
ُ
ﻳ .ﺓﺩﺭﻔﻧﻣﻟﺍ ﺕﺍﻭﻧﻘﻠﻟ AUX 2 ﻡﻳﻠﺳﺗ ﻝﻛ ﻉﻭﻣﺟﻣ ﻥﻣ ﺔﻧﻭﻛﻣ ﺔﻧﺯﺍﻭﺗﻣ ﺭﻳﻏ ﻁﺧ ﺓﺭﺎﺷﺇ ﺝﺭﺎﺧﻟﺍ ﻰﻟﺇ ﻝﺻﻭﻣﻟﺍ ﺱﺑﺎﻘﻟﺍ ﺍﺫﻫ ﻝﺳﺭﻳ
.ﻥﻳﺗﻣﺧﺿﻣ ﺡﺭﺳﻣ ﺔﺷﺎﺷﻟ ﻭﺃ ﻲﺟﺭﺎﺧ ﺭﻳﺛﺄﺗ
(3 ﺩﻋﺎﺳﻣ ﺱﺑﺎﻗ ﻝﺧﺩﻣ) AUX SEND 3 .48
ﻝﺧﺩ ﻝﻳﺻﻭﺗﻟ ﺓﺩﺎﻋ ﻡﺩﺧﺗﺳ
ُ
ﻳ .ﺓﺩﺭﻔﻧﻣﻟﺍ ﺕﺍﻭﻧﻘﻠﻟ AUX 3 ﻡﻳﻠﺳﺗ ﻝﻛ ﻉﻭﻣﺟﻣ ﻥﻣ ﺔﻧﻭﻛﻣ ﺔﻧﺯﺍﻭﺗﻣ ﺭﻳﻏ ﻁﺧ ﺓﺭﺎﺷﺇ ﺝﺭﺎﺧﻟﺍ ﻰﻟﺇ ﻝﺻﻭﻣﻟﺍ ﺱﺑﺎﻘﻟﺍ ﺍﺫﻫ ﻝﺳﺭﻳ
ﺓﺩﺎﻋ ﻡﺗﻳ ،ﺓﺎﻧﻗ ﻝﻛﻟ POST ﺭﺯ ﻊﺿﻭ ﻰﻠﻋ ﺩﻣﺗﻌﻳ ﺍﺫﻫﻭ post fader ﻭﺃ pre ﺓﺭﺎﺷﻹﺍ ﻩﺫﻫ ﻥﻭﻛﺗ ﻥﺃ ﻥﻛﻣﻳ .ﻥﻳﺗﻣﺧﺿﻣ ﺡﺭﺳﻣ ﺔﺷﺎﺷﻟ ﻭﺃ ﻲﺟﺭﺎﺧ ﺭﻳﺛﺄﺗ
.post ﻭﺃ pre ﺎﻣﺇ ﺭﺍﺭﺯﻷﺍ ﻩﺫﻫ ﻁﺑﺿ
(4 ﺩﻋﺎﺳﻣ ﺱﺑﺎﻗ ﻝﺧﺩﻣ) AUX SEND 4 .49
ﻝﺧﺩ ﻝﻳﺻﻭﺗﻟ ﺓﺩﺎﻋ ﻡﺩﺧﺗﺳ
ُ
ﻳ .ﺓﺩﺭﻔﻧﻣﻟﺍ ﺕﺍﻭﻧﻘﻠﻟ AUX 4 ﻡﻳﻠﺳﺗ ﻝﻛ ﻉﻭﻣﺟﻣ ﻥﻣ ﺔﻧﻭﻛﻣ ﺔﻧﺯﺍﻭﺗﻣ ﺭﻳﻏ ﻁﺧ ﺓﺭﺎﺷﺇ ﺝﺭﺎﺧﻟﺍ ﻰﻟﺇ ﻝﺻﻭﻣﻟﺍ ﺱﺑﺎﻘﻟﺍ ﺍﺫﻫ ﻝﺳﺭﻳ
.ﺓﺎﻧﻘﻟﺍ ﻯﻭﺗﺳﻣ ﻲﻓ ﻡﻛﺣﺗﻟﺍ ﻊﺿﻭ ﻰﻠﻋ (post-fader) ﺓﺭﺎﺷﻹﺍ ﻩﺫﻫ ﺩﻣﺗﻌﺗ .ﻥﻳﺗﻣﺧﺿﻣ ﺡﺭﺳﻣ ﺔﺷﺎﺷﻟ ﻭﺃ ﻲﺟﺭﺎﺧ ﺭﻳﺛﺄﺗ
(ﺕﺍﺩﻋﺎﺳﻣﻟﺍ ﺱﺑﺎﻗ ﻝﺧﺩﻣ) AUX RETURN .50
ﺍﺫﻫ ﻡﺍﺩﺧﺗﺳﺍ ﻥﻛﻣﻳ .(ﻻﻭﺻﻔﻣ R ﻝﺧﺩﻣﻟﺍ ﻲﻘﺑ ﺍﺫﺇ MONO ـﻛ L ﻝﺧﺩﻣﻟﺍ ﻡﺍﺩﺧﺗﺳﺍ ﻥﻛﻣﻳ :ﺔﻅﺣﻼﻣ) stereo ﺩﻋﺎﺳﻣ ﻝﺧﺩﻣﻟ ﺔﻧﺯﺍﻭﺗﻣ ﺭﻳﻏ ﺱﺑﺎﻗ ﺕﻼﺻﻭﻣ
.ﻁﺧﻟﺍ ﻯﻭﺗﺳﻣﺑ ﺭﺩﺻﻣ ﻱﺃ ﻝﻳﺻﻭﺗﻟ ﻭﺃ ﻲﺟﺭﺎﺧﻟﺍ ﺭﻳﺛﺄﺗﻟﺍ ﻥﻣ ﺓﺩﻭﻌﻟﺍ ﺓﺭﺎﺷﻹ ﻝﺧﺩﻟﺍ
(ﺩﻋﺎﺳﻣ ﻝﺧﺩﻣ ﻯﻭﺗﺳﻣ) AUX RETURN TO MIX .51
.MAIN MIX ﺝﺭﺧﻣ ﻰﻟﺇ ﻪﻠﺳﺭﻳﻭ ،AUX RETURN ﻝﺧﺩﻣﻟﺍ ﻯﻭﺗﺳﻣ ﻡﻅﻧﻳ
(ﺩﻋﺎﺳﻣ ﻝﺧﺩﻣ ﻯﻭﺗﺳﻣ) AUX RETURN TO AUX1 .52
.AUX 1 SEND ﺝﺭﺧﻣ ﻰﻟﺇ ﻪﻠﺳﺭﻳﻭ AUX RETURN ﻝﺧﺩﻣ ﻯﻭﺗﺳﻣ ﻡﻅﻧﻳ
(ﺩﻋﺎﺳﻣ ﻝﺧﺩﻣ ﻯﻭﺗﺳﻣ) AUX RETURN TO AUX2 .53
.AUX 2 SEND ﺝﺭﺧﻣ ﻰﻟﺇ ﻪﻠﺳﺭﻳﻭ AUX RETURN ﻝﺧﺩﻣ ﻯﻭﺗﺳﻣ ﻡﻅﻧﻳ
(GROUPS 1-2 ﺝﺭﺧﻣ ﻯﻭﺗﺳﻣ ﻲﻓ ﻡﻛﺣﺗﻟﺍ) GROUPS 1-2 FADER .54
GRP" ﺭﺯ ﻰﻠﻋ ﻁﻐﺿﻟﺍ ﻡﺗ ﺍﺫﺇ ﻭﺃ ﻪﺑ ﻥﻳﺻﺎﺧﻟﺍ ﻥﻳﺟﺭﺧﻣﻟﺍ ﻝﺑﻗ GROUPS 1-2 ﻝﻗﺎﻧ ﺓﺭﺎﺷﺇ ﺝﺭﺧﻣ ﻯﻭﺗﺳﻣ ﻲﻓ fader GROUPS 1-2 ﻡﻛﺣﺗﻳ
.MAIN MIX ﻝﻗﺎﻧ ﻰﻠﻋ ﺍﺩﺩﺟﻣ ﺭﺩﺻ
ُ
ﺗ ﻥﺃ ﻝﺑﻗ ،"TO MIX
(GROUPS 1-2 al MIX ﻥﻳﻳﻌﺗ ﺭﺯ) GRP TO MIX .55
GROUPS 1-2 ﻡﺍﺩﺧﺗﺳﺍ ﻥﻛﻣﻳ ﺭﺯﻟﺍ ﺍﺫﻫ ﻰﻠﻋ ﻁﻐﺿﻟﺎﺑ ،ﺎﻔﻧﺁ ﺢﺿﻭﻣ ﻭﻫ ﺎﻣﻛ ،MAIN MIX ﻝﻗﺎﻧﻟﺍ ﻰﻠﻋ GROUPS 1-2 ﻝﻗﺎﻧﻟﺍ ﺭﺯﻟﺍ ﺍﺫﻫ ﻥﻳﻌﻳ
.ﺩﺣﺍﻭ ﺽﺑﻘﻣﺑ ﺕﺍﻭﻧﻘﻟﺍ ﺽﻌﺑ ﻯﻭﺗﺳﻣ ﻲﻓ ﻡﻛﺣﺗﻟﺎﺑ ،ﻲﻋﺭﻔﻟﺍ ﻁﻠﺧﻟﺍ ﻥﻣ ﺔﻋﻭﻣﺟﻣﻛ
(MIX ﺝﺭﺧﻣ ﻯﻭﺗﺳﻣ) MAIN MIX FADER .56
MAIN MIX ﺢﺑﺻﻳ ،ﺎﻳﻧﺩﻟﺍ ﻩﺩﻭﺩﺣ ﻲﻓ fader ـﻟﺍ ﻥﻭﻛﻳ ﺎﻣﺩﻧﻋ .MAIN MIX ﺝﺭﺧﻣ ﻝﺑﻗ ﺎﻣﺎﻣﺗ ﺝﺭﺧﻣﻟﺍ ﻯﻭﺗﺳﻣ ﻲﻓ MAIN MIX FADER ﻡﻛﺣﺗﻳ
،"0" ﻥﻣ ﺎﺑﻳﺭﻗ fader ـﻟﺍ ﺍﺫﻫ ﻥﻳﻳﻌﺗ ﺓﺩﺎﻋ ﻡﺗﻳ .ﻝﺑﻳﺳﻳﺩ ﺓﺩﺣﻭ +4 ـﺑ ﻥﺯﺍﻭﺗﻣ ﻝﺑﻛ ﻰﻠﻋ ﺝﺭﺧﻣﻠﻟ ﻲﻣﺳﻻﺍ ﻯﻭﺗﺳﻣﻟﺍ ﻥﺃ ﻰﻠﻋ ﻝﺩﺗ "0" ﺔﻁﻘﻧ ﺎﻣﻧﻳﺑ ،ﺎﻘﻠﻐﻣ
.ﺓﺭﻭﺭﺿﻟﺍ ﺔﻟﺎﺣ ﻲﻓ ﺔﻋﺭﺳﺑ ﺕﻭﺻﻟﺍ ﺔﻣﻭﻅﻧﻣ ﺕﺎﻛﺳﺇ ﻭﺃ ﺕﺎﻳﻧﻏﻷﺍ ﻝﻳﻠﻅﺗﻟ ﺎﺿﻳﺃ ﻪﻣﺍﺩﺧﺗﺳﺍ ﻥﻛﻣﻳ ﻥﻛﻟﻭ ،ﺎﻧﻫ ﻙﺭﺗﻳﻭ
(ﻥﺯﺍﻭﺗﻣ ﺭﻳﻏ ﺝﺭﺧﻣ ﺱﺑﺎﻗ) GROUPS 1-2 .57
ﻯﻭﺗﺳﻣ ﻡﻛﺣﺗﺑ ﻡﻅﻧﻣ stereo GROUPS 1-2 ﻝﻗﺎﻧ ﻥﻣ (ﻝﺑﻳﺳﻳﺩ ﺓﺩﺣﻭ +4) ﻥﺯﺍﻭﺗﻣ ﺭﻳﻏ ﻁﺧ ﻯﻭﺗﺳﻣ ﺓﺭﺎﺷﺇ JACK ﺱﺑﺎﻘﻟﺍ ﺕﻼﺻﻭﻣ ﻲﻁﻌﺗ
.fader GROUPS 1-2
(MAIN MIX ﺭﻳﺛﺄﺗﺑ ﺝﺭﺧﻣ ﻝﺧﺩﻣ) MAIN MIX INSERT .58
ﺔﻗﻭﺎﻌﻣﺑ ﻡﻳﻠﺳﺗﻟﺍ .ﺕﺎﺋﻓﺎﻛﻣﻭ ﻁﻏﺍﻭﺿ ﻥﻋ ﺓﺭﺎﺑﻋ ﺓﺩﺎﻋ ﺕﺍﺭﻳﺛﺄﺗﻟﺍ ﻩﺫﻫﻭ .MAIN MIX FADER ﻡﻛﺣﺗﻟﺍ ﻝﺑﻗ ﺱﺑﺍﻭﻘﻟﺍ ﻩﺫﻬﺑ ﺔﻠﺳﻠﺳﺗﻣ ﺕﺍﺭﻳﺛﺄﺗ ﻝﻳﺻﻭﺗ ﻥﻛﻣﻳ
ﻥﻣ ﻉﻭﻧ ﻱﺄﺑ ﻪﻠﻳﺻﻭﺗ ﻥﻛﻣﻳﻭ (ﻡﻭﺃ 10) ﺔﻳﻟﺎﻋ ﺔﻗﻭﺎﻌﻣﺑ ﻉﻭﺟﺭﻟﺍ .ﻲﻁﺧﻟﺍ ﻯﻭﺗﺳﻣﻟﺍ ﺕﺍﺫ ﺕﺎﻣﻭﻅﻧﻣﻟﺍ ﻥﻣ ﻉﻭﻧ ﻱﺃ ﺓﺭﺍﺩﺇ ﻰﻠﻋ ﺭﺩﺎﻗ ،(ﻡﻭﺃ 150) ﺔﺿﻔﺧﻧﻣ
DHT540 ﻉﻭﻧﻟﺍ PROEL ﺡﺭﺗﻘﺗ .ﺭﺟﺎﺗﻣﻟﺍ ﻲﻓ ﺓﺭﻓﻭﺗﻣﻭ ،ﻝﺎﻣﻌﺗﺳﻻﺍ ﻥﻣ ﻉﻭﻧﻟﺍ ﺍﺫﻬﻟ ﺔﺻﺻﺧﻣ "Y" ﺔﺻﺎﺧ ﺕﻼﺑﻛ .ﻲﻁﺧﻟﺍ ﻯﻭﺗﺳﻣﻟﺍ ﺕﺍﺫ ﺕﺎﻣﻭﻅﻧﻣﻟﺍ
.ﻝﻳﻟﺩﻟﺍ ﺍﺫﻫ ﻥﻣ ﺕﻼﻳﺻﻭﺗﻟﺍ ﻝﺻﻓ ﺎﺿﻳﺃ ﻊﺟﺍﺭ .(ﻡﺩﻗ 5.9 - ﺭﺗﻣ (1.8
(ﻥﺯﺍﻭﺗﻣ jackﻭ MAIN XLR ﺝﺭﺧﻣ) MAIN MIX L & R .59
.MAIN MIX ﻭﻳﺭﺗﺳﺍ ﻝﻗﺎﻧﻠﻟ (ﻝﺑﻳﺳﻳﺩ ﺓﺩﺣﻭ +4) ﻥﺯﺍﻭﺗﻣ ﻁﺧ ﻯﻭﺗﺳﻣ ﻱﺫ ﺎﺟﺭﺧﻣ JACKﻭ XLR ﺕﻼﺻﻭﻣ ﻲﻁﻌﺗ
ﻦﻜﻤﻳ ،ﻚ ﻟﺫ ﻰﻠﻋ ءﺎﻨﺑﻭ . phantom power ﻂﻴﺸﻨﺗ ﻥﻭﺪ ﺑ ﻭﺃ ﻊﻣ ﻥﺯﺍﻮﺘﻣ ﻂﺧ ﻰﻠﻋ ﺓﺭﺎ ﺷﺇ ﻝﺎ ﺳﺭﺇ ﻊﻴﻄﺘﺴﻳ ﺎﻴﻠﻌﻓ ﻥﺯﺍﻮﺘﻣ ﺝﺮﺨﻣ ﻦﻋ ﺓﺭﺎﺒﻋ MAIN OUT ﻥﺇ :ﺔﻈﺣﻼﻣ
.ﻲﺴﻴﺋﺮﻟﺍ ﻁﻼﺨﻟﺍ ﻰﻟﺇ ﺓﺭﺎﺷﺇ ﻝﺎﺳﺭﻹ DI ﻕﻭﺪﻨﺻ + ﻁﻼﺧ ﺔﻔﻴﻟﻮﺘﻛ M1622USB ﻡﺍﺪﺨﺘﺳﺍ
(rca stereo ﻝﺧﺩﻣ) 2TRK IN .60
،CD/DVD ﺉﺭﺎﻗ ﻭﺃ MP3 ﺉﺭﺎﻗ ،ﻱﺭﻅﺎﻧﺗﻟﺍ ﻝﺟﺳﻣﻟﺍ ﻝﺛﻣ ﻁﺧ ﺭﺩﺻﻣ ﺝﺭﺧﻣ ﻝﻳﺻﻭﺗﻟ RCA ﺕﻼﺻﻭﻣ ﻊﻣ ﺔﻧﺯﺍﻭﺗﻣﻟﺍ ﺭﻳﻏ ﻝﺧﺍﺩﻣﻟﺍ ﻩﺫﻫ ﻡﺩﺧﺗﺳ
ُ
ﺗ
.ﺭﺗﻭﻳﺑﻣﻛﻟ ﻲﺗﻭﺻ ﺝﺭﺧﻣ
(ﻯﻭﺗﺳﻣﻟﺍ ﻲﻓ ﻡﻛﺣﺗﻟﺍ) USB/2TRK IN LEVEL .61
.USB ﺱﺑﻘﻣ ﻥﻣ ﺓﺩﺭﺍﻭﻟﺍ ﺓﺭﺎﺷﻹﺍﻭ ،2TRK IN ﻝﺧﺩﻣ ﻯﻭﺗﺳﻣ ﻡﻅﻧﻳ
(USB/2TRK IN ﻥﻳﻳﻌﺗ ﺭﺯ) MIX / CH15/16 .62
ﻊﻣ ﻥﻛﻣﻣﻟﺍ ﻥﻣ 15/16 ﺓﺎﻧﻗ ﺭﺑﻋ ﺭﻭﺭﻣﻟﺎﺑﻭ .15/16 ﺓﺎﻧﻘﻟﺍ ﻰﻟﺇ ﻭﺃ MAIN MIX ﻰﻟﺇ ﺓﺭﺷﺎﺑﻣ USB/2 TRK IN ﻝﺧﺩﻣ ﻥﻣ ﺔﻣﺩﺎﻘﻟﺍ ﺓﺭﺎﺷﻹﺍ ﻥﻳﻌﻳ
.ﻲﻠﺧﺍﺩﻟﺍ ﺭﻳﺛﺄﺗﻟﺍ ﻰﻟﺇﻭ AUX ﻰﻟﺇ ﺔﻟﺎﺣﻹﺍﻭ ﺅﻓﺎﻛﺗﻟﺍ :MAIN MIX ﻰﻟﺇ ﺎﻬﻟﺎﺳﺭﺇ ﻝﺑﻗ stereo ﺓﺎﻧﻗ ﻁﺑﺍﻭﺿ ﻊﻳﻣﺟ ﻡﺍﺩﺧﺗﺳﺍ ﺓﺭﺎﺷﻹﺍ
(USB/2TRK OUT ﺝﺭﺧﻣ ﺔﻣﻗ ﻑﺷﺎﻛ) PEAK .63
ﻲﻓ ﻡﻛﺣﺗﻟﺍ ﻡﺍﺩﺧﺗﺳﺎﺑ ﺝﺭﺧﻣﻟﺍ ﻯﻭﺗﺳﻣ ﺽﻔﺧ ،ﺔﻟﺎﺣﻟﺍ ﻩﺫﻫ ﻲﻓ .2TRK OUTﻭ USB ﺝﺭﺧﻣ ﻉﺎﻁﻘﻧﺍ ﻥﻣ ﺏﻳﺭﻗ ،ﺍﺩﺟ ﻲﻟﺎﻋ ﺝﺭﺧﻣ ﻯﻭﺗﺳﻣ ﻥﻋ ﻎﻠﺑﻳ
.USB/2TRK OUT ﻯﻭﺗﺳﻣ
