PROEL MQ10FX - Power Input and Switch; Technical Specification

12
35. 18V~ supply socket input
Here’s where you plug in your mixer’s external power supply. You should always connect your power supply
to the mixer before you plug the power supply into an electrical outlet.
36. POWER switch
Switch this one on and your mixer has power. Switch it off and it doesn’t. Make sure that all master output
knobs are turned all the way down when powering your mixer up or down.
37. Power cable hook
Use this hook to prevent power cable drawing, simply go through it before connecting the cable into the
18V~ socket.
TECHNICAL SPECIFICATION
Type
Data
Connectors
Mic Input 1-6
sensitivity
from -10 to -50 dB
Balanced XLR-F
impedance
2 Kohm
Line Input 1-6
sensitivity
from +20 to -20 dB
Balanced JACK
impedance
10 Kohm
Lo cut
75Hz, 18dB/oct.
EQ
HIGH (shelving)
±15 dB @ 12KHz
MID (peaking)
±15 dB @ 2.5KHz
LOW (shelving)
±15 dB @ 80Hz
Compressor 1-2
Fet
1 control knob
Line Input 7-10
sensitivity
-10 dB
Balanced JACK, RCA
impedance
10 Kohm
MAIN MIX output
nom. out level
+4 dBu
Balanced JACK and XLR-M
C. ROOM output
nom. out level
0 dBu
Unbalanced JACK
FX SEND output
nom. out level
0 dBu
Unbalanced JACK
HEADPHONES output
min. impedance
32 ohm
Stereo JACK
max. out level
(2x) 193 mW
Effects
100 presets
A/D and D/A converters
24 bit
DSP resolution
24 bit
Controls
2-DIGIT display, DIAL, PEAK LED, MUTE
switch, MUTE footswitch
Maximum level
all outputs
+22 dBu
Crosstalk
meas. at 1 KHz
> 82 dB
HUM & Noise
unweighted
< -93 dBu
THD + Noise
at +4dB, 1kHz
< 0,008 %
Dimensions (WxHxD)
275 x 275 x 76 mm
Weight
2,50 kg
Supply
18 VAC 1000 mA
use only supplied AC/AC ADAPTER
Mains Supply Voltage
110-120 VAC (±10%) 50 / 60 Hz (US plug)
230-240 VAC (±10%) 50 / 60 Hz (EU plug)
240 VAC (±10%) 50 / 60 Hz (UK plug)
Consumption
34 W
