PROEL MQ6 - Technical Specification

9
TECHNICAL SPECIFICATION
Type
Data
Connectors
Mic Input 1-2
sensitivity
from -10 to -50 dB
Balanced XLR-F
impedance
2 Kohm
Line Input 1-2
sensitivity
from +20 to -20 dB
Balanced JACK
impedance
10 Kohm
Lo cut
75Hz, 18dB/oct.
EQ
HIGH (shelving)
±15 dB @ 12KHz
LOW (shelving)
±15 dB @ 80Hz
Line Input 3-6
sensitivity
-10 dB
Unbalanced JACK
impedance
10 Kohm
MAIN MIX output
nom. out level
+4 dBu
Balanced JACK and XLR-M
HEADPHONES output
min. impedance
32 ohm
Stereo JACK
max. out level
(2x) 193 mW
Maximum level
all outputs
+22 dBu
Crosstalk
meas. at 1 KHz
> 82 dB
HUM & Noise
unweighted
< -93 dBu
THD + Noise
at +4dB, 1kHz
< 0,008 %
Dimensions (WxHxD)
162 x 210 x 51 mm
Weight
1,00 kg
Supply
18 VAC 1000 mA
use only supplied AC/AC ADAPTER
Mains Supply Voltage
110-120 VAC (±10%) 50 / 60 Hz (US plug)
230-240 VAC (±10%) 50 / 60 Hz (EU plug)
240 VAC (±10%) 50 / 60 Hz (UK plug)
Consumption
34 W
