PROEL SW115HA - Technical Specifications; SW115 HA Model Specifications; Specifiche Tecniche SW115 HA

3
INDICE / INDEX
specifi cations
Index
FCC COMPLIANCE NOTICE . . . . . . . . . . . . . . . . . . . . 2
TECHNICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . . 3
FREQUENCY RESPONSE . . . . . . . . . . . . . . . . . . . . . . 4
DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
ACTIVE - CONNECTIONS (FIG. 1) . . . . . . . . . . . . . . . 5
CONTROL PANEL (FIG.2) . . . . . . . . . . . . . . . . . . . . . . 5
CONFIGURATION EXAMPLES (FIG. 3) . . . . . . . . . . . 6
SAFETY AND PRECAUTIONS . . . . . . . . . . . . . . . . . . 7
IN CASE OF FAULT . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . 7
CE CONFORMITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
PACKAGING, SHIPPING AND COMPLAINT . . . . . . 8
WARRANTY AND PRODUCTS RETURN . . . . . . . . . . 8
INSTALLATION AND DISCLAIMER . . . . . . . . . . . . . . 8
POWER SUPPLY AND MAINTENANCE . . . . . . . . . . 8
GENERAL INFORMATION . . . . . . . . . . . . . . . . . . . . . 9
SW115HA - INSTRUCTIONS ( FIG. 1 / 2 / 3) . . . . . . . 9
Indice
SPECIFICHE TECNICHE . . . . . . . . . . . . . . . . . . . . . . . 3
RISPOSTA IN FREQUENZA . . . . . . . . . . . . . . . . . . . . 4
DIMENSIONI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
ACCESSORI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
ATTIVA - CONNESSIONI (FIG. 1) . . . . . . . . . . . . . . . . 5
PANNELLO DI CONTROLLO (FIG. 2) . . . . . . . . . . . . . 5
ESEMPI CONFIGURAZIONI (FIG. 3) . . . . . . . . . . . . . 6
AVVERTENZE PER LA SICUREZZA . . . . . . . . . . . . . 11
IN CASO DI GUASTO . . . . . . . . . . . . . . . . . . . . . . . . 11
PROBLEMATICHE COMUNI . . . . . . . . . . . . . . . . . . . 11
CONFORMITÀ CE . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
IMBALLAGGIO, TRASPORTO E RECLAMI . . . . . . . 12
GARANZIE E RESI . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
INSTALLAZIONE E LIMITAZIONI D’USO . . . . . . . . 12
ALIMENTAZIONE E MANUTENZIONE . . . . . . . . . . 12
INFORMAZIONI GENERALI . . . . . . . . . . . . . . . . . . . 13
SW118HA - ISTRUZIONI (FIG. 1 / 2 / 3) . . . . . . . . . . 13
MODEL SW115HA
System type BPS enclosure subwoofer
Frequency Response (-10dB) 37 Hz - 160 Hz
LP Crossover Frequency switchable 100 Hz / 160 Hz
Loudspeaker 15'' woofer - 3" VC
Amplifi er Continuous Power 500 W Class D
Max SPL 128 dBspl
Connectors IN: 2 x NEUTRIK COMBO
OUT: 2 x NEUTRIK XLR-M
LINK: 2 x NEUTRIK XLR-M
Controls Level, GND lift
Filter Frequency, Phase
Input Impedance 30 kohm balanced
15 kohm unbalanced
Input Sensitivity 0 dBu / 0.775 V
Angular coverage omnidirectional
Construction 15/18 mm plywood
Finishing Anti-scratch BLACK paint fi nish
Mounting Pole 1
Transport 2 x steel handles
4 x 75 mm wheels
Weight 32 kg (70.5 lb)
Dimensions (W x H x D) 430 x 550 x 600 mm
Power Supply 230 VAC or 120 VAC - 50/60 Hz
see label on the apparatus
Maximun Consumption 730 VA
Rated Consumption* 220 VA
* Rated consumption is measured with pink noise with a crest factor of 12 dB,
this can be considered a standard music program.
TECHNICAL SPECIFICATIONS SPECIFICHE TECNICHE
MODELLO SW115HA
Sistema subwoofer Band Pass Serie
Risposta in Frequenza (-10dB) 37 Hz - 160 Hz
Frequenza di Crossover selezionabile 100 Hz / 160 Hz
Altoparlante 15'' woofer - 3" VC
Potenza Continua Amplifi catore 500 W Classe D
Massima SPL 128 dBspl
Connettori IN: 2 x NEUTRIK COMBO
OUT: 2 x NEUTRIK XLR-M
LINK: 2 x NEUTRIK XLR-M
Controlli Level, GND lift
Filter Frequency, Phase
Impedenza ingresso 30 kohm balanced
15 kohm unbalanced
Sensibilità ingresso 0 dBu / 0.775 V
Copertura angolare omni
Costruzione multistrato 15/18 mm
Finitura Vernice NERA anti-graffi o
Flangia supporto SAT 1
Trasporto 2 x maniglie
4 x 75 mm ruote
Peso 32 kg
Dimensioni (L x H x P) 430 x 550 x 600 mm
Alimentazione 230 VAC o 120 VAC - 50/60 Hz
vedi etichetta sull'apparecchio
Consumo massimo 730 VA
Consumo nominale* 220 VA
* Il consumo nominale è misurato con rumore rosa con un fattore di cresta di 12 dB,
questo può essere considerato un programma standard di musica.
