INSTALLATION
SP. A
2 INCH MINIMUM
FOR PROPER AIR FLOW
1 INCH MIN
FOR PROPER
AIR FLOW
1 INCH MIN
FOR PROPER
AIR FLOW
ALWAYS KEEP TOP AND
BOTTOM VENTS CLEAR
TO MAINTAIN PROPER AIR FLOW,
PLACE OTHER COMPONENTS
ON SEPARATE SHELVES
VENT HOLES IN SHELF IMPROVE AIR FLOW
Diagram 4 M40 Air Flow Requirements
AIR FLOW





