M10 x 78mm Carriage Bolt (50)
M10 Nylon Locknut (64)
M6 x 25mm Button Screw (57)
M6 x 38mm Button Screw (53)
M10 x 22mm Bolt Set (66)
M4 x 25mm Round Head Screw (47)
M4 x 16mm Screw (76)
M6 x 25mm Screw (77)
M6 x 16mm Screw (55)
M6 x 45mm Screw (78)
PART IDENTIFICATION CHART
R
efer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART LIST in the center of this manual.
Note: Some small parts
may have been pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached.
