ProForm PFEL51016.1 User Manual

11
5
6
Avoid pinching the
Main Wire (110) and
avoid damaging the
tabs (A)
A
4
1
105
105
99
99
B
110
4
4
110
B
6. Locate the wire tie (B) in the lower end of the
Upright (4). Tie the wire tie to the Main Wire
(110). Then, pull the upper end of the wire tie
until the Main Wire is routed through the Upright.
Tip: To prevent the Main Wire (110) from
falling into the Upright (4), secure the Main
Wire with the wire tie (B).
5. Tip: Avoid pinching the Main Wire (110).
Avoid damaging the indicated plastic tabs
(A). Have a second person hold the Upright (4)
on the Frame (1).
Attach the Upright (4) with four M10 x 25mm
Screws (99) and four M10 Split Washers (105);
start all the Screws, and then tighten them.
110

ProForm PFEL51016.1 Specifications

General

Brand	ProForm
Model	PFEL51016.1
Category	Elliptical Trainer
Language	English
