9
7. Attach the Left Handrail (88) to the Left Upright
(89) with two 5/16" x 1" Bolts (5), two 5/16" Star
Washers (11), and a 5/16" x 1 1/4" Bolt (4). Do
not fully tighten the Bolts yet.
Attach the Right Handrail (87) in the same
way.
7
89
88
87
4
4
5
5
11
11
6. Cut the plastic tie in the Left Handrail (88) and
the Right Handrail (not shown). If necessary,
press the 5/16" Cage Nuts (31) back into place.
I
dentify the Left Handrail (88) and hold it near
the Left Upright (89). Insert the Upright Wire
(81) through the bracket on the bottom of the
Left Handrail. Pull the Upright Wire out of the
e
nd of the Left Handrail.
88
6
89
31
81
Tie
To Next Page
