30
DIMENSIONS DES ENROULEURS CROISIERE
DIMENSIONS OF CRUISING SYSTEMS
C290 C320 C350 C420 C430
Standard Standard
Avale ridoir/
Turnbuckle cylinder
Standard
Avale ridoir/
Turnbuckle cylinder
Standard
Avale ridoir/
Turnbuckle cylinder
Standard
Avale ridoir/
Turnbuckle cylinder
mm ins mm ins mm ins mm ins mm ins mm ins mm ins mm ins mm ins
A 44 1’47/64'' 44 1 47/64'' Voir/See Standard 68 2 43/64'' Voir/See Standard 68 2 43/64'' Voir/See Standard 68 2 43/64'' Voir/See Standard
B 10 13/32’’ 10 13/32’’ Voir/See Standard 10 13/32'' Voir/See Standard 10 13/32'' Voir/See Standard 10 13/32'' Voir/See Standard
C 22 55/64’’ 22 55/64’’ Voir/See Standard 28 17/64'' Voir/See Standard 28 17/64'' Voir/See Standard 28 17/64'' Voir/See Standard
D 120 4’3/4’’ 180 7 3/32'' Voir/See Standard 200 7 3/4'' Voir/See Standard 220 8 21/32'' Voir/See Standard 220 8 21/32'' Voir/See Standard
ØD1 140 5 33/64'' 200 7 7/8'' Voir/See Standard 222 8 3/4'' Voir/See Standard 242 9 17/32'' Voir/See Standard 242 9 17/32'' Voir/See Standard
E 79 3’1/8’’ 79 3’1/8’’ Voir/See Standard 103 4 1/16'' Voir/See Standard 103 4 1/16'' Voir/See Standard 140 5 33/64'' Voir/See Standard
F 293 11 1/2'' 461 1 6 1/4'' 575 1' 10 3/4'' 442 1 5 1/2'' 762 2' 6 442 1' 5 1/2'' 808 2' 7 3/4'' 442 1' 5 1/2'' 808 2' 7 3/4''
G 96 3 3/4'' 96 3 3/4'' Voir/See Standard 125 4 7/8'' Voir/See Standard 126 4 61/64'' Voir/See Standard 170 6 11/16'' Voir/See Standard
Hmax 320 1 5/8'' 110 4’ 21/64'' 424 1' 4 3/4'' 137 5 25/64'' 457 1' 5 63/64'’ 154 6 1/16'' 520 1' 8 1/2'' 154 6 1/16'' 520 1' 8 1/2''
I 109 4 1/2’’ 109 4 1/2’’ Voir/See Standard 142 5 19/32'' Voir/See Standard 144 5 43/64'' Voir/See Standard Voir/See Standard
J 100 3 7/8’’ 72 2’53/64'' Voir/See Standard 72 2 53/64'' Voir/See Standard 72 2 53/64'' Voir/See Standard 72 2 53/64'' Voir/See Standard
K 33 1 1/4' 33 1’1/4'’ Voir/See Standard 47 1 27/32'' Voir/See Standard 47 1 27/32'' Voir/See Standard 47 1 27/32'' Voir/See Standard
L 404 1' 3 7/8'' 181 7 1/4’’ 495 1' 7 1/2'' 220 8 3/4'' 540 1 9 1/4'' 236 9 19/64'' 601 1' 11 1/2'' 236 9 19/64'' 601 1' 11 1/2''
L1 18 45/64’’ 18 45/64’’ Voir/See Standard 20 25/32'' Voir/See Standard 20 25/32'' Voir/See Standard 20 25/32'' Voir/See Standard
M 78 35/64’’ 64 2’33/64’’ Voir/See Standard 75 2 15/16'' Voir/See Standard 75 2 15/16'' Voir/See Standard 75 2 15/16'' Voir/See Standard
N 25 63/64’’ 17 43/64’’ Voir/See Standard 21 53/64'' Voir/See Standard 18 45/64'' Voir/See Standard 18 45/64'' Voir/See Standard
O 45 1 49/64’’ "
P 150 5 29/32’’ 157 6 3/16'' Voir/See Standard 184 7 1/4'' Voir/See Standard 203 7’ 1 63/64’’ Voir/See Standard 203 7’ 1 63/64’’ Voir/See Standard
Q 98 3 55/64’’ 88 3’15/32'' Voir/See Standard 108 4 1/4'' Voir/See Standard 115 4 17/32'' Voir/See Standard 115 4 17/32'' Voir/See Standard
R 80 3 5/32’’ 66 2’19/32'' Voir/See Standard 86 3 25/64'' Voir/See Standard 90 3 9/16'' Voir/See Standard 90 3 9/16'' Voir/See Standard
S 170 6 11/64’’
Tmax 29 1 9/64’’ 32 1 17/64'' Voir/See Standard 42 1 21/32'' Voir/See Standard 42 1 21/32'' Voir/See Standard 42 1 21/32'' Voir/See Standard
U 213 8 25/64’’ 199 7 53/64'' Voir/See Standard 245 9 41/64'' Voir/See Standard 262 10 1/2'' Voir/See Standard 262 10 1/2'' Voir/See Standard
V 66 2 19/32’’ 92 3 5/8'' Voir/See Standard 105 4 9/64'' Voir/See Standard 105 4 9/64'' Voir/See Standard 105 4 9/64'' Voir/See Standard
W 97 3’13/16’’ 97 3 13/16'' Voir/See Standard 115 4 17/32'' Voir/See Standard 115 4 17/32'' Voir/See Standard 115 4 17/32'' Voir/See Standard
X 46 1 13/16’’ 52 2 3/64'' 60 2 23/64'' " 60 2 23/64'' 60 2 23/64''
Y 29 1 9/64’’ 32 1 17/64'' Voir/See Standard 35 13/8'' Voir/See Standard 42 1 21/32'' Voir/See Standard 42 1 21/32'' Voir/See Standard
Z 10370 34 1/4’’ 12160 39' 10 3/4'' 12475 39' 10 3/4' 14215 46' 7 3/4'' 14535 47' 8 1/4'' 16230 53' 2 16595 54' 5 1/2'' 18230 59' 9 1/2'' 18595 61'
LL LL LM LL LM LL LM LL LM
a 180 7’3/32'' 340 1' 1 1/12'' 180 7’3/32'' 500 1 7 11/16'' 200 7 7/8’’ 500 1' 7 3/4'' 200 7 7/8'' 500 1' 7 3/4'' 250 9 27/32''
b 145 5’45/64'' 305 1 1/64'' 145 5’7/8'' 465 1 6 5/16'' 165 6 3/4'' 465 1' 6 5/16'' 165 6 3/4'' 465 1' 6 5/16'' 215 8 21/32''
c 110 4 21/64'' 270 10 5/8'' 110 4 21/64'' 430 1’4 7/8'' 130 5 1/2'' 430 1’ 4 7/8'' 130 5 1/2’’ 430 1’ 4 7/8'' 180 7 31/64''
d 75 2 61/64'' 235 9’1/4'' 75 2 61/64'' 395 1’ 3 9/16'' 95 4 5/16'' 395 1’ 3 9/16'' 95 4 5/16'' 395 1’ 3 9/16'' 145 6 19/64''
e 4 5/32'' 4 5/32'' 4 5/32'' 4 5/32'' 4 5/32'' 4 5/32'' 4 5/32'' 4 5/32'' 4 5/32''
f 16 19/32'' 16 19/32'' 16 19/32'' 16 43/64'' 16 19/32'' 16 43/64'' 16 19/32'' 16 43/64'' 16 19/32''
g 41 1’39/64'' 41 1 39/64'' 41 1 39/64'' 41 1 39/64'' 41 1 39/64'' 41 1 39/64'' 41 1 39/64'' 61 2 9/16'' 61 2 9/16''
LL= Lattes Longues / Long Link Plates
LM= Lattes Moyennes / Medium Link Plates
