WARNING: TORQUE ALL CONNECTIONS PER LABEL – EXCESSIVE TORQUE MAY CAUSE DAMAGE TO
CONNECTIONS LEADING TO A FIRE CAUSING PROPERTY DAMAGE, SERIOUS INJURY OR DEATH.
WARNING: SHOCK HAZARD - DUE TO THE HIGH VOLTAGES ASSOCIATED WITH ITS OPERATION
ONLY QUALIFIED SERVICE PERSONNEL SHOULD INSTALL OR TROUBLESHOOT THIS TRANSFER SWITCH!
ALL APPLICABLE CODES AND STANDARDS MUST BE MET WHEN INSTALLING THIS DEVICE. SEE WIRING
DIAGRAM INSIDE OF THE COVER AND ON THE BACK OF THIS PAGE. IMPROPER HANDLING OR INSTALLA-
TION MAY CAUSE SERIOUS INJURY OR DEATH.
WARNING: THE 5100 AUTOMATIC TRANSFER SWITCHES ARE NOT IGNITION PROTECTED AND SHOULD
NOT BE MOUNTED IN THE SAME COMPARTMENT AS THE BATTERIES OR FLAMMABLE MATERIALS SUCH
AS GASOLINE. DO NOT MOUNT THE TRANSFER SWITCH IN THE GENERATOR OR LP GAS COMPARTMENT. A
FIRE CAUSING PROPERTY DAMAGE SERIOUS INJURY OR DEATH COULD RESULT!
The 5100 Automatic Transfer Switches are not suitable for outdoor locations and should be mounted on a flat surface with 4
screws (not included) in a protected area. We recommend that the transfer switch be mounted as close to the shore power and
generator power cords as practical to reduce voltage loss.
Description of Operation
When the shore power is applied the relay is at rest and power is transferred to the panel.
When Generator power is applied there is a 20-45 second delay and then the relay activates transferring Generator power
to the panel.
If shore power returns while the Gen power is present nothing will happen. When the Gen power is removed the relay will
drop out and allow the shore side to supply power.
Generator overrides shore power.
Consult a licensed electrician or an RV technician for installation assistance
Page 1
Installation Instructions
!
Specifications
(Specifications subject to change without notice)
Model
PD5110010 PD5110610 PD5121010
Electrical rating
120 VAC 60Hz @ 30A 120 VAC 60Hz @ 30A
120/240 VAC 60Hz @ 50A
(Single hot leg)
Dimensions
9.65”L x 7.28”W x 4.75”H 9.65”L x 7.28”W x 4.75”H 9.65”L x 7.28”W x 4.75”H
Weight
3 lbs 3 lbs 4 lbs
To Next Page
