INSTALLATION

STEP 1: Take the bike frame out of the box.

STEP 2: Attach the front base(14) to the Main Frame using the carriage bolt(15),Washer(8) and the

Domed Nut(13) and tighten with a wrench.

STEP 3:Attach the rear base (18) to the Main Frame using the carriage bolt(15), Washer(8) and the Domed Nut(13)

and tighten with a wrench.

STEP 4:Insert the Saddle Post(21) to the main frame,fasten it with adjusting Knob(11).

STEP 5:Attach the Saddle Slider (24) to the Saddle Post (21), fasten it using a Washer (23) and Knob (22).

STEP 6:Attach the saddle(25) to the saddle slider(24), tighten with a wrench.
