Project Source 0877812 - Temperature Setting

11
13. Remove valve cap.
12. Turn on water and check for leaks.
ASSEMBLY INSTRUCTIONS
14. Turn the valve counterclockwise to the full
position. After several minutes, check the
temperature using the thermometer. Slowly turn
the valve clockwise to adjust the maximum water
temperature to the desired temperature.
CAUTION: The maximum water temperature
should never be set above 120°F (49°C).
14
2
13
12
14
13
12
120º F Max
49º C Max
1
b
c
a
b
c
a
