TOE-KICK ASSEMBLY INSTRUCTION
STEP- 1
STEP- 2 STEP- 3
EE
EE
MM
• Measure the back of your toe
kicks as per the above diagram.
Once you have determined the
location of the leg clips, mark
the screw hole position with a
pencil.
• Using a punch or drill bit,
make a pilot hole in the screw
hole position.
• Using a Phillips head screwdriver, secure the
leg clip with the 5/8" Pan head screws as
demonstrated in the illustration.
