Project Source 5217236 - Assembly Instructions; Step 1: Wooden Dowel Insertion; Step 2: Minifix Shaft Fastening; Step 3: Minifix Cam Lock Insertion

6
ASSEMBLY INSTRUCTIONS
Hardware Used
Hardware Used
Hardware Used
Minix shaft
Minix cam lock
Wooden dowel
x 12
x 13
x 18
1
2
3
BB
AA
JJ
BB
AA
JJ
1. Using a rubber mallet, tap in wooden dowels in the
correct positions as per the illustration. For added
strength, apply a small amount of wood glue to each
dowel prior to placement (not included).
2. Using a phillips head screwdriver, fasten
the minix shafts in the correct positions as
shown.
3. Insert the minix cam lock in the correct positions
based on the illustration. Please note the arrow mark
should face the bore hole as per the illustration.
