ASSEMBLY INSTRUCTIONS
10
1
2
10
all
G
10. Check for leaks at tub stub-out pipe. Next wrap
stub-out pipe with thread seal tape and install
spout (G).
11. Check for leaks at shower arm (A). Next divert
water to the shower to flush out the water lines.
12. Install shower head (C) to shower arm (A). Hand
tighten shower head.
11
12
1
11
12
A
A
C
2
12
