Project Timber Evolution My Den 8x6 - Page 12

REAR - Wall Panels Section Stages
RIGHT - Gable Wall Panels Section Stages
Panel Position Diagram
Front of Building
Rear
Side
(Left)
Side
(Right)
Side
(RIGHT)
Back
Right Opening
Window (High)
Panel
Right Gable
(Low) Panel
Cloaking Strip
1. Right Window Gable
Panel - HIGH (1)
2. Right Gable
Panel - LOW (1)
3. Gable Cloaking Strip (1)
60mmx16mmx2050mm
Parts List required:
16mm
2094mm
585mm
Lining
Flush
16mm
2135mm
1220mm
Lining Flush
Right Window Panel
(HIGH) Diagram
Right Gable Panel
(LOW) Diagram
ID: PT25532 ID: PT25522
Back
Position and fix the back panel
(RIGHT) and cloaking strip
Back Panel Stages
50mm
Screws
ID: PT25542
