PURLIN FIXING
Check the purlin dimensions.
“Check the dimensions
of your parts”
HOBBYIST PENT
ASSEMBLY INSTRUCTIONS
STAGE 4
page on mobile"
"Pinch to zoom the
Pilot drill holes before fixing
Purlin fixing
Position and fix in
place the purlin to the
wall panels.
Front
30mm
Screws
Pilot drill holes
before fixing
Front
Panel
Purlin
Purlin fixing
Back
4mm
30mm
Screws
Pilot drill holes
before fixing
Position and fix in
place the purlin to the
wall panels.
Back
Panel
Purlin
4mm
