Projecta IntelliJay PM200-BTJ User Manual

22
8. SPECIFICATION
Table 19 Specication of PM235J
MODEL PM235J
ELECTRICAL SPECIFICATIONS
Mains Nominal input voltage
(V)
240±10%VAC
50/60Hz
Power factor 0.95
Input current at full
load
2.5A
Battery Vehicle battery 12VDC
Vehicle battery
voltage range
12.8-16VDC
House battery 12VDC
House battery voltage
range
10.5-16VDC
Solar Charger type PWM
Open circuit voltage 25VDC
Max charging current 30A
Maxium solar input 800W
Charging
Relay
Relay specication 12VDC 60A
continuous,
peak current
100A, 30mins
Connect voltage
Lead Acid - 13.4VDC
LiFePO
4
- 13.7VDC
Connect delay time 10sec
Disconnect voltage
Lead Acid - 12.8VDC
LiFePO
4
- 13.3VDC<2A
Disconnect delay time 60sec
High voltage limit 16.0VDC
Charger
Mode
Charge Algorithms 5 Stage
Battery type AGM/GEL/LFP
(LiFePO
4
)//WET
Start voltage 2V for Lead Acid
0V for LFP
Bulk current 30A (Max)
Absorption voltage (14.4/14.1
/14.4/14.7)
±0.15VDC
Float voltage (13.5/13.5
/13.5/13.7)
±0.13VDC
Power
Supply
Mode
Nominal output
voltage
12.8±0.2 VDC
Rated output current 35A
(Continuous)
Efciency 88%
Working temperature -40°C~+65°C
(50°C:full load;
60°C:20A; 65°C:
shutdown the
output)
MODEL PM235J
ELECTRICAL SPECIFICATIONS
Battery
Disconnect
(LVD)
Disconnect voltage AGM/GEL/WET 10.5VDC
(default)
LFP (LiFePO
4
) 11.2 VDC
(Default)
Delay off time 60 sec
Reconnect voltage AGM/GEL/WET 11.5VDC
(default)
LFP (LiFePO
4
) 12.2 VDC
(Default)
Current draw
on Battery
240VAC is off, no
vehicle charging
330mA
Load switch off 255mA
LVD off,
Service<10.5V current
draw on battery
180mA
Battery switch OFF
<10V draw on battery
0mA
Fused outputs Numbers 14
Rated Current 10A x 11, 15A x 3
Protection Short circuit on output Fuse blown
Reverse polarity Diode reverse isolation
Overload protection Derate the output until overload
is removed
Battery charger over
temperature
Shut down PM235J
Ambient over
temperature
Alarm
Battery over voltage
limits
Battery charger disconnect,
loads disconnect
PHYSICAL SPECIFICATIONS
Dimensions
(L*W*H)
264 × 164 × 128mm
Weight 3kgs
Enclosure Steel Case
Battery
Connector
M4 Screw (16mm
2
)
Load Connector Wago804-114 (2.5mm
2
) Wago2706-103 (6mm
2
)
Cooling Forced cooling
Protection
category
IP20
Approvals
Electrical AS/NZS 60335.2.29
EMC CISPR14
